11.15 U: MONITORS
498 SIEPYEUOQ2A01G AC Drive Q2A Technical Manual
No.
(Hex.)
Name Description MFAO Signal Level Ref.
U4-25
(07E7)
No of Travels(H) Shows the lower 4 digits of the drive run count.
Note:
The keypad shows the drive run count in 8 digits. Monitor U4-25 shows the upper 4
digits and U4-24 [No of Travels(L)] shows the lower 4 digits.
No signal output
available
-
U4-52
(1592)
Torque Ref from Comm Displays the torque reference given to the drive via a serial communication option card
or via Modbus communications as a decimal number.
Unit: 0.1%
No signal output
available
-
U5: PID
No.
(Hex.)
Name Description MFAO Signal Level Ref.
U5-01
(0057)
PID Feedback Shows the PID control feedback value. Parameter b5-20 [PID Unit Selection] sets the
display units.
Unit: 0.01%
10 V: Maximum
frequency (-10 V to +10
V)
-
U5-02
(0063)
PID Input Shows the change between the PID setpoint and PID feedback (the quantity of PID
input) as a percentage of the maximum output frequency.
Unit: 0.01%
10 V: Maximum
frequency (-10 V to +10
V)
-
U5-03
(0064)
PID Output Shows the PID control output as a percentage of the maximum output frequency.
Unit: 0.01%
10 V: Maximum
frequency (-10 V to +10
V)
-
U5-04
(0065)
PID Setpoint Shows the PID setpoint. Parameter b5-20 [PID Unit Selection] sets the display units.
Unit: 0.01%
10 V: Maximum
frequency (-10 V to +10
V)
-
U5-05
(07D2)
PID Diff.Feedbk Shows the PID differential feedback value as a percentage of the maximum output
frequency.
This monitor is available after setting H3-02, H3-10, or H3-06 = 11 [MFAI Function
Select = Diff PIDFbk].
Unit: 0.01%
10 V: Maximum
frequency (-10 V to +10
V)
-
U5-06
(07D3)
PID AdjustFeedback Shows the difference from calculating U5-05 - U5-01 [PID Diff.Feedbk] - [PID
Feedback].
Unit: 0.01%
Note:
U5-01 = U5-06 when H3-02, H3-10, or H3-06 11 [MFAI Function Select = Diff
PIDFbk].
10 V: Maximum
frequency (-10 V to +10
V)
-
U5-21
(0872)
Expert
Energy Save Ki Coeff Shows the energy-saving coefficient Ki value for PM.
Unit: 0.01
No signal output
available
-
U5-22
(0873)
Expert
Energy Save Kt Coeff Shows the energy-saving coefficient Kt value for PM.
Unit: 0.01
No signal output
available
-
U5-82
(3070)
Expert
InsP_PID_Out_IN Reserved monitor. Contact Omron for details.
Unit: 0.01%
10 V: Maximum
frequency (-10 V to +10
V)
-
U5-83
(3071)
Expert
InsP_PID_Out_OUT Reserved monitor. Contact Omron for details.
Unit: 0.01%
10 V: Maximum
frequency (-10 V to +10
V)
-
U5-84
(3072)
Expert
InsP_Frq_Ref_IN Reserved monitor. Contact Omron for details.
Unit: 0.01%
10 V: Maximum
frequency (-10 V to +10
V)
-
U5-85
(3073)
Expert
InsP_Frq_Ref _OUT Reserved monitor. Contact Omron for details.
Unit: 0.01%
10 V: Maximum
frequency (-10 V to +10
V)
-
U5-88
(3076)
Expert
InsP_Trq_Ref_IN Reserved monitor. Contact Omron for details.
Unit: 0.01%
10 V: Maximum
frequency (-10 V to +10
V)
-
U5-89
(3077)
Expert
InsP_Trq_Ref _OUT Reserved monitor. Contact Omron for details.
Unit: 0.01%
10 V: Maximum
frequency (-10 V to +10
V)
-
U5-90
(3078)
Expert
InsP_Run_Ref_IN Reserved monitor. Contact Omron for details.
Unit: 0.0001
No signal output
available
-
