12.7 H: TERMINALS
SIEPYEUOQ2A01G AC Drive Q2A Technical Manual 709
Note:
Refer to Modbus communications “Self-Diagnostics” for the self-diagnostics procedure.
■ 90 to 99: Q2pack DI1 to 10
Setting Function Description
90 to 99 Q2pack DI1 to 10
Sets digital inputs used with Q2pack. Refer to the Q2pack Online Manual for more information.
Note:
You cannot set values 90 to 99 for inverse output.
■ 9F: Q2pack Disable
Setting Function Description
9F Q2pack Disable
Sets operation of the Q2pack program saved in the drive.
Note:
Set A1-07 = 2 [Q2pack Enable = With DI] to use this function.
ON : Disabled
OFF : Enabled
■ 101 to 19F: Inverse Input of 1 to 9F
Setting Value Function Description
101 to 19F Inverse Input of 1 to 9F Sets the function of the selected MFDI to operate inversely. To select the function, enter “1xx”, where the “xx” is the function
setting value.
For example, to use the inverse input of 46 [ASR I Reset], set H1-xx = 146.
Note:
You cannot use inverse input for all functions. Refer to Table 12.39 for more information.
◆ H2: DIGITAL OUTPUTS
■ Multi-Function Digital Outputs
H2 parameters set the MFDO terminal functions.
H2-01 Multi-Function Digital Output 1, H2-02 Multi-Function Digital Output 2, H2-03 Multi-Function Digital
Output 3
The drive has three MFDO terminals. Table 12.44 shows the default function settings for the terminals.
Table 12.44 MFDO Terminals Default Function Settings
No. Name Default Setting Function
H2-01 Multi-Function Digital Output 1 5 @Run
H2-02 Multi-Function Digital Output 2 7 Zero Speed
H2-03 Multi-Function Digital Output 3 F SpeedAgree1
Refer to Table 12.45 to set H2-xx [DO Function Select].
Table 12.45 MFDO Setting Value
Setting Value Function
0
*1
Through Mode
1 Drive Ready
2 Drive Enable
3 Fault
4 Alarm
5 @Run
6 @Reverse
7 Zero Speed
Setting Value Function
8 ZeroServo ok
9 @Regeneration
A @SpeedLimit
B @FreqOutput
C @Standby
D LO/RE Status
E EDM Safety
F SpeedAgree1
To Next Page
