12.10 o: KEYPAD
840 SIEPYEUOQ2A01G AC Drive Q2A Technical Manual
■ o4-22 Time Format
No.
(Hex.)
Name Description
Default
(Range)
o4-22
(154F)
RUN
Time Format
Sets the time display format. This parameter is only available when using an LCD keypad.
0
(0 - 2)
Sets the display of the time shown in the upper-left of the LCD keypad screen.
0 : 24 Hour Clock
1 : 12 Hour Clock
2 : 12 Hour JP Clock
■ o4-23 Date Format
No.
(Hex.)
Name Description
Default
(Range)
o4-23
(1550)
RUN
Date Format
Sets the date display format. This parameter is only available when using an LED keypad.
0
(0 - 2)
Sets the date format that the drive uses for the fault history and other records.
0 : YYYY/MM/DD
1 : DD/MM/YYYY
2 : MM/DD/YYYY
Note:
The Fault History in the Monitor Mode shows when faults occurred. Refer to Show Fault History on page 141 for more information.
■ o4-24 bAT Detection Selection
No.
(Hex.)
Name Description
Default
(Range)
o4-24
(310F)
RUN
bAT Detection Selection
Sets operation when the drive detects bAT [Keypad Battery Low Voltage] and TiM [Keypad Time
Not Set].
0
(0 - 2)
0 : Disabled
The drive will not detect bAT or TiM.
1 : Enable (Alarm Detected)
TiM or bAT shows on the keypad, and operation continues. The output terminal set for Alarm [H2-01 to H2-03 =
4] activates.
2 : Enable (Fault Detected)
The drive output shuts off and the motor coasts to stop. Fault relay output terminal 1NO-1CM activates, and 1NC-
1CM deactivates.
◆ o5: DATA LOGGER
The data log function saves drive status information as a CSV file in the micro SD memory card in the keypad.
Monitors Ux-xx are the source of data log information. You can record a maximum of 10 monitors.
Change the LCD keypad screen from the main menu to the Diagnostic Tools screen and select the data log
function. Set the number of the monitor to record and the sampling time, then start to record the data log.
Table 12.58 Setting Parameters for Data Log Items
No. Name Default Data Log Monitors
o5-03 Log Mon Data 1 101 U1-01 [Frequency Reference]
o5-04 Log Mon Data 2 102 U1-02 [Output Frequency]
o5-05 Log Mon Data 3 103 U1-03 [Output Current]
o5-06 Log Mon Data 4 107 U1-07 [DC Bus Voltage]
o5-07 Log Mon Data 5 108 U1-08 [Output Power]
o5-08 Log Mon Data 6 000 Not selected
