Page #841 background imageLoading...
Page #841 background image
Parameter Details
12
12.10 o: KEYPAD
SIEPYEUOQ2A01G AC Drive Q2A Technical Manual 841
No. Name Default Data Log Monitors
o5-09 Log Mon Data 7 000 Not selected
o5-10 Log Mon Data 8 000 Not selected
o5-11 Log Mon Data 9 000 Not selected
o5-12 Log Mon Data 10 000 Not selected
NOTICE: Do not de-energize the drive or disconnect the keypad from the drive during log transfer communication. Failure to
obey can cause the log function to fail after you restore power or connect the keypad.
Note:
You can use a Micro SDHC card a maximum of 32 GB capacity.
Log File Specifications
Item Specification
File storage location A folder called [Log_File] is created in the root directory of the micro SD card.
Filename Q0xxx.csv
Note:
[xxx] identifies a 3-digit decimal number
Maximum number of files
999 (Q0001.csv through Q0999.csv)
Character code ASCII code
Line break code <CR><LF>
Separating character Commas
Header rows First row: Drive information including Drive Model, software version, control method, and sampling time
Second row: Log data information including the monitor number, number decimal points, and unit code
Log File Configuration
The [Log_Files] folder is created in the root directory of the micro SD card. This is where the log data is stored as
CSV files. Log data files are created in this configuration. The number of rows changes when the number of
selected monitors change.
First row Drive information
Second row Log data information
Third row Log data 1
: Log data 2
: Log data 3
: :
Last row Log data n
First Row: Drive Information
This example shows the data text strings and data generated for the first row of log data.
Example of generated data: 00,0012,160107111230,Q2A,VSAA01010,2,62,1000,000001
No. Item
Number
of
Charac
ters
Example Description
1 Attribute 2 00 [00] shows that the record is a drive information record.
2 File number 4 0012 The [xxx] part of the [Q0xxx.csv] filename is a 3-digit decimal number in hexadecimal format.
Example filename of [Q0018.csv]: 018 (Dec.) = 0012 (Hex.)
3 Time stamp
*1
12 160107111230 Date file was generated
Date: 20YY/MM/DD
Time in 24-hour format: HH:MM:SS
Example data of [160107111230]: 11:12:30 on January 7, 2016
4 Model 3 Q2A Drive model information
5 Software number 9 VSAA01010 Drive software number
6 Control method 1 2 Setting value (Hex.) of A1-02 [Control Method]
7 Drive capacity 2 62 Setting value (Hex.) of o2-04 [Drive KVA Selection]
