12.10 o: KEYPAD
842 SIEPYEUOQ2A01G AC Drive Q2A Technical Manual
No. Item
Number
of
Charac
ters
Example Description
8 Sampling time 5
(maximum)
1000 Setting value (Dec.) of o5-02 [Log Sample Lapse]
Unit: ms
9 Row number 6 000001 Row number (Hex.) in the data log file
*1 If you do not set the time in the keypad, the text string of [000000000000] is generated to show the time.
Second Row: Log Data Information
This example shows the data text strings and data generated for the second row of log data.
Example of generated data:
01,0012,160107111230,0101,0201,0102,0201,0103,0206,0107,0005,0108,0209,0000,0000,0000,0000,0000,0
000,0000,0000,0000,0000,0000,0000,0000,0000,000002
No. Item
Number of
Characters
Description
1 Attribute 2 [01] shows that the record is a log data information record.
2 File number 4 The [xxx] part of the [Q0xxx.csv] filename is a 3-digit decimal number in hexadecimal format.
3 Time stamp 12 Date file was generated
4 Monitor number 1
*1
4 Monitor number selected by o5-03 [Log Mon Data 1]
Ex.: 0101 (Dec.) for U1-01
5 Monitor Unit 1
*2
4 Unit code and number of decimal places used for the monitor selected with o5-03
Example when U1-01 = 30.00 Hz:
Number of decimal places = 2, Hz unit code = 01, monitor unit 1 = 0201 (Hex.)
6 Monitor number 2 4 Monitor number (Dec.) selected by o5-04 [Log Mon Data 2]
7 Monitor Unit 2 4 Unit code and number of decimal places used for the monitor selected with o5-04
: : : :
22 Monitor number 10 4 Monitor number (Dec.) selected by o5-12 [Log Mon Data 10]
23 Monitor Unit 10 4 Unit code and number of decimal places used for the monitor selected with o5-12
24 to 27 Reserved 4 -
28 Row number 6 Row number (Hex.) in the data log file
*1 If there is no data log monitor selected, the text string of [0000] is generated.
*2 Refer to Table 12.59 for information about unit codes.
Table 12.59 Unit Codes
Unit Code (Hex.) Unit Unit Code (Hex.) Unit Unit Code (Hex.) Unit Unit Code (Hex.) Unit
00 – 08 PPR 10 H 18 0H
01 Hz 09 kW 11 V 19 –
02 RPM 0A Ω 12 us 1A –
03 % 0B ms 13 min 1B –
04 VAC 0C kHz 14 °C 1C –
05 VDC 0D PSI 15 W 1D –
06 A 0E MPM 16 kWH 1E –
07 sec 0F FPM 17 MWH 1F –
Third and Subsequent Rows: Log Data
This example shows the data text strings and data generated for the third row of log data.
Example of generated data:
02,0012,160107111239,1770,1770,00BE,0118,0028,0000,0000,0000,0000,0000,0000,0000,00000C
No. Item
Number of
Characters
Description
1 Attribute 2 [02] shows that the record is a monitor data record.
2 File number 4 The [xxx] part of the [Q0xxx.csv] filename is a 3-digit decimal number in hexadecimal format.
3 Time stamp 12 Data log data was retrieved (YYMMDDHHMMSS)
4 Log Monitor Data 1 4 Log monitor data (Hex.) of the monitor selected with o5-03 [Log Mon Data 1]
