Parameter Details
12
12.10 o: KEYPAD
SIEPYEUOQ2A01G AC Drive Q2A Technical Manual 843
No. Item
Number of
Characters
Description
5 Log Monitor Data 2 4 Log monitor data (Hex.) of the monitor selected with o5-04 [Log Mon Data 2]
: : : :
13 Log Monitor Data 10 4 Log monitor data (Hex.) of the monitor selected with o5-12 [Log Mon Data 10]
14 Reserved 4 -
15 Encoding data 4 Encoding data for log monitor data 1 through 10 (Hex.)
Bits 0 through 9 show the encoding of log monitor data 1 1 through 10. A bit value of 1 shows that the data represents
a negative value. (Log monitor data 1 through 10 is absolute value data without encoding)
Example when log monitor data 2, 5, and 8 show negative values: Bits 1, 4, and 7 have values of 1, and the encoding
data = 0010010010 (Bin.) = 0092 (Hex.)
16 Row number 6 Row number (Hex.) in the data log file
■ o5-01 Log Start Selection
No.
(Hex.)
Name Description
Default
(Range)
o5-01
(1551)
RUN
Log Start Selection
Sets the data log function. This parameter is only available on an LCD keypad.
0
(0 - 1)
0 : OFF
Stops the data log.
1 : ON (Data Logging)
Starts the data log as specified by the sampling cycle set in o5-02 [Log Sample Lapse].
■ o5-02 Log Sample Lapse
No.
(Hex.)
Name Description
Default
(Range)
o5-02
(1552)
RUN
Log Sample Lapse
Sets the data log sampling cycle. This parameter is only available on an LCD keypad.
1000 ms
(100 - 6000 ms)
■ o5-03 Log Mon Data 1
No.
(Hex.)
Name Description
Default
(Range)
o5-03
(1553)
RUN
Log Mon Data 1
Sets the data log monitor. This parameter is only available on an LCD keypad.
101
(000,101 - 855)
Note:
Set the log data with values 101 to 999 [U1-01 to U9-99].
For example, to show U1-05 [Motor Speed], set o5-03 = 105. When it is not necessary to set data log monitors, set this parameter to
000. You cannot set U2: FAULT or U3: FAULT HISTORY.
■ o5-04 Log Mon Data 2
No.
(Hex.)
Name Description
Default
(Range)
o5-04
(1554)
RUN
Log Mon Data 2
Sets the data log monitor. This parameter is only available on an LCD keypad.
102
(000,101 - 855)
Note:
Set the log data with values 101 to 999 [U1-01 to U9-99].
For example, to show U1-05 [Motor Speed], set o5-03 = 105. When it is not necessary to set data log monitors, set this parameter to
000. You cannot set U2: FAULT or U3: FAULT HISTORY.
