11.20 Parameters Changed by PM Motor Code Selection
520 SIEPYEUOQ2A01G AC Drive Q2A Technical Manual
◆ Yaskawa SST4 Series IPM Motors (Constant Torque)
Table 11.13 SST4 Series Motor Code Setting for Specification of 400 V at 1750 min
-1
(r/min)
No. Name Unit Motor Code (setting value of E5-01)
E5-01
PM Mot Code Selection - 2232 2233 2235 2236 2238 223A 223B 223D
Voltage Class V 400 400 400 400 400 400 400 400
Capacity kW 0.4 0.75 1.5 2.2 3.7 5.5 7.5 11
Motor Rotation Speed min
-1
1750 1750 1750 1750 1750 1750 1750 1750
E5-02
PM Mot Rated Power
(kW)
kW 0.4 0.75 1.5 2.2 3.7 5.5 7.5 11.0
E5-03
PM Mot Rated Current
(FLA)
A 0.92 1.77 3.33 4.48 7.50 10.42 14.27 20.5
E5-04 PM Mot Pole Count - 6 6 6 6 6 6 6 6
E5-05
PM Mot Resistance
(Ohms/Phase)
Ω 8.935 4.570 3.096 1.906 0.972 1.103 0.630 0.429
E5-06
PM d-Axis Inductance
(mH/Phase)
mH 80.14 48.04 35.60 30.31 20.03 23.41 14.86 14.34
E5-07
PM q-Axis Inductance
(mH/Phase)
mH 110.76 64.88 47.84 38.36 24.97 28.70 17.25 17.25
E5-09
PM BackEMF Vpeak
(mV/(rad/ s))
mVs/rad 416.5 399.4 438.5 475.5 463.7 485.8 470.4 513.4
E5-24
PM BackEMF L-L
Vrms (mV/rpm)
mV/(r/
min)
0.0 0.0 0.0 0.0 0.0 0.0 0.0 0.0
E1-04 Max Output Frequency Hz 87.5 87.5 87.5 87.5 87.5 87.5 87.5 87.5
E1-05 Max Output Voltage V 380.0 380.0 380.0 380.0 380.0 380.0 380.0 380.0
E1-06 Base Frequency Hz 87.5 87.5 87.5 87.5 87.5 87.5 87.5 87.5
E1-09 Min Output Frequency Hz 4.4 4.4 4.4 4.4 4.4 4.4 4.4 4.4
C5-17 Motor Inertia kgm
2
0.0016 0.0022 0.0042 0.0081 0.0133 0.013 0.017 0.027
L3-24
*1
Acc@Rated Torque s 0.134 0.099 0.094 0.124 0.121 0.081 0.075 0.082
n5-02
Mot Inertia
Acceleration Time
s 0.134 0.099 0.094 0.124 0.121 0.081 0.075 0.082
n8-49 Heavy Load Id Current % -7.5 -8.5 -9.8 -8.2 -9.1 -13.1 -9.2 -12.4
*1 Default settings vary depending on the setting of o2-04 [Drive KVA Selection].
Table 11.14 SST4 Series Motor Code Setting for Specification of 400 V at 1750 min
-1
(r/min)
No. Name Unit Motor Code (setting value of E5-01)
E5-01
PM Mot Code Selection - 223E 223F 2240 2242 2243 2244 2245 2246
Voltage Class V 400 400 400 400 400 400 400 400
Capacity kW 15 18 22 30 37 45 55 75
Motor Rotation Speed min
-1
1750 1750 1750 1750 1750 1750 1750 1750
E5-02
PM Mot Rated Power
(kW)
kW 15 18.50 22.00 30.00 37.00 45.00 55.00 75.00
E5-03
PM Mot Rated Current
(FLA)
A 26.4 34.2 38.8 52.2 65.4 77.6 99.3 130.2
E5-04 PM Mot Pole Count - 6 6 6 6 6 6 6 6
E5-05
PM Mot Resistance
(Ohms/Phase)
Ω 0.275 0.196 0.160 0.120 0.077 0.052 0.036 0.023
E5-06
PM d-Axis Inductance
(mH/Phase)
mH 9.99 7.92 6.82 5.24 3.57 2.98 1.59 1.59
E5-07
PM q-Axis Inductance
(mH/Phase)
mH 12.37 9.64 8.51 6.44 4.65 3.75 2.78 1.97
E5-09
PM BackEMF Vpeak
(mV/(rad/ s))
mVs/rad 505.3 489.2 509.5 566.2 531.6 530.6 515.2 515.2
E5-24
PM BackEMF L-L
Vrms (mV/rpm)
mV/(r/
min)
0.0 0.0 0.0 0.0 0.0 0.0 0.0 0.0
E1-04 Max Output Frequency Hz 87.5 87.5 87.5 87.5 87.5 87.5 87.5 87.5
E1-05 Max Output Voltage V 380.0 380.0 380.0 380.0 380.0 380.0 380.0 380.0
