Q2 Q2A User Manual

Parameter List
11
11.20 Parameters Changed by PM Motor Code Selection
SIEPYEUOQ2A01G AC Drive Q2A Technical Manual 519
Parameter Unit Motor Code (setting value of E5-01)
Motor Rotation Speed min
-1
1150 1150 1150 1150 1150 1150
E5-02 PM Mot Rated Power (kW) kW 15 18.50 22.00 30.00 37.00 45.00
E5-03 PM Mot Rated Current (FLA) A 27.8 31.8 37.2 52.1 64.8 76.6
E5-04 PM Mot Pole Count - 6 6 6 6 6 6
E5-05 PM Mot Resistance (Ohms/Phase) Ω 0.331 0.264 0.192 0.140 0.093 0.063
E5-06 PM d-Axis Inductance (mH/Phase) mH 15.09 13.32 9.52 8.16 6.13 4.63
E5-07 PM q-Axis Inductance (mH/Phase) mH 18.56 18.00 12.60 11.40 9.10 6.15
E5-09 PM BackEMF Vpeak (mV/(rad/ s)) mVs/rad 749.6 842.7 821.8 872.3 857.7 866.6
E5-24 PM BackEMF L-L Vrms (mV/rpm) mV/(r/min) 0.0 0.0 0.0 0.0 0.0 0.0
E1-04 Max Output Frequency Hz 57.5 57.5 57.5 57.5 57.5 57.5
E1-05 Max Output Voltage V 380.0 380.0 380.0 380.0 380.0 380.0
E1-06 Base Frequency Hz 57.5 57.5 57.5 57.5 57.5 57.5
E1-09 Min Output Frequency Hz 2.9 2.9 2.9 2.9 2.9 2.9
C5-17 Motor Inertia kgm
2
0.064 0.116 0.140 0.259 0.312 0.418
L3-24 Acc@Rated Torque
*1
s 0.062 0.091 0.092 0.125 0.122 0.135
n5-02 Mot Inertia Acceleration Time s 0.062 0.091 0.092 0.125 0.122 0.135
n8-49 Heavy Load Id Current % -14.9 -17.9 -15.9 -17.7 -20.1 -13.8
*1 Default settings vary depending on the setting of o2-04 [Drive KVA Selection].
Table 11.12 SSR1 Series Motor Code Setting for Specification of 400 V at 1150 min
-1
(r/min)
No. Unit Motor Code (setting value of E5-01)
E5-01 PM Mot Code Selection - 1445 1446 1447 1448
Voltage Class V 400 400 400 400
Capacity kW 55 75 90 110
Motor Rotation Speed min
-1
1150 1150 1150 1150
E5-02 PM Mot Rated Power (kW) kW 55.00 75.00 90.00 110.00
E5-03 PM Mot Rated Current (FLA) A 92.0 127.1 150.5 185.4
E5-04 PM Mot Pole Count - 6 6 6 6
E5-05 PM Mot Resistance (Ohms/Phase) Ω 0.051 0.033 0.027 0.015
E5-06 PM d-Axis Inductance (mH/Phase) mH 3.96 3.03 2.60 1.89
E5-07 PM q-Axis Inductance (mH/Phase) mH 5.00 5.14 3.28 2.33
E5-09 PM BackEMF Vpeak (mV/(rad/ s)) mVs/rad 854.0 823.1 853.4 829.2
E5-24 PM BackEMF L-L Vrms (mV/rpm) mV/(r/min) 0.0 0.0 0.0 0.0
E1-04 Max Output Frequency Hz 57.5 57.5 57.5 57.5
E1-05 Max Output Voltage V 380.0 380.0 380.0 380.0
E1-06 Base Frequency Hz 57.5 57.5 57.5 57.5
E1-09 Min Output Frequency Hz 2.9 2.9 2.9 2.9
C5-17 Motor Inertia kgm
2
0.56 0.83 0.96 1.61
L3-24 Acc@Rated Torque
*1
s 0.147 0.161 0.154 0.212
n5-02 Mot Inertia Acceleration Time s 0.147 0.161 0.154 0.212
n8-49 Heavy Load Id Current % -12.5 -28.8 -13.3 -11.6
*1 Default settings vary depending on the setting of o2-04 [Drive KVA Selection].
