7.3 List of Fault, Minor Fault, Alarm, and Error Codes
SIEPYEUOQ2A01G AC Drive Q2A Technical Manual 263
7.3 List of Fault, Minor Fault, Alarm, and Error Codes
The following table shows the possible fault, minor fault, alarm, and error codes.
The display codes are in alphabetical order. Search the table for the code shown on the keypad, and identify its
causes and possible solutions.
Note:
The number in parentheses adjacent to the code in the table identifies the fault code or minor fault code (hex. number) that was read
during Modbus communications.
Example: AEr (0032)
Table 7.2 List of Fault, Minor Fault, Alarm, and Error Codes
Display (Hex.) ALM LED Type Ref.
AEr (0032) Flashing Alarm 285
bAT (0085) Flashing Alarm 285
bAT (0402) Illuminated Fault 266
bb (0008) Flashing Alarm 285
bCE (008A) Flashing Alarm 285
bCE (0416) Illuminated Fault 266
boL (0045) Flashing Alarm 285
boL (004F) Illuminated Fault 266
bUS (0015) Flashing Alarm 285
bUS (0022) Illuminated Fault 266
CALL (001D) Flashing Alarm 286
CE (0014) Flashing Alarm 286
CE (0021) Illuminated Fault 266
CF (0025) Illuminated Fault 267
CoF (0046) Illuminated Fault 267
CP1 (0087) Flashing Alarm 286
CP1 (0414) Illuminated Fault 267
CP2 (0088) Flashing Alarm 287
CP2 (0415) Illuminated Fault 268
CPEr -
Copy Function
Error
305
CPF00, CPF01
CPF02, CPF03 (0083,
0084)
CPF07, CPF08 (0088,
0089)
CPF11 to CPF14 (008C to
008F)
CPF16 to CPF24 (0091 to
0099)
CPF26 to CPF38 (009B to
00A7)
CPF40 to CPF45 (00A9 to
00AE)
Illuminated Fault 268
CPF06 (0087) Illuminated Fault 268
CPF25 (009A) Illuminated Fault 268
CPyE -
Copy Function
Error
305
CrST Flashing Not an alarm. 287
CSEr -
Copy Function
Error
305
CyC (0033) Flashing Alarm 287
dEv (0011) Flashing Alarm 287
dEv (0019) Illuminated Fault 268
Display (Hex.) ALM LED Type Ref.
dFPS -
Copy Function
Error
305
dnE (002A) Flashing Alarm 287
dv1 (0032) Illuminated Fault 268
dv2 (0033) Illuminated Fault 268
dv3 (0034) Illuminated Fault 269
dv4 (0035) Illuminated Fault 269
dv7 (005B) Illuminated Fault 269
E5 (0031) Flashing Alarm 287
E5 (0039) Illuminated Fault 270
EF (0007) Flashing Alarm 287
EF0 (001A) Flashing Alarm 287
EF0 (0027) Illuminated Fault 270
EF1 (0042) Illuminated Fault 270
EF1 (0039) Flashing Alarm 288
EF2 (003A) Flashing Alarm 288
EF2 (0043) Illuminated Fault 270
EF3 (0009) Flashing Alarm 288
EF3 (0011) Illuminated Fault 270
EF4 (000A) Flashing Alarm 288
EF4 (0012) Illuminated Fault 270
EF5 (000B) Flashing Alarm 288
EF5 (0013) Illuminated Fault 270
EF6 (000C) Flashing Alarm 288
EF6 (0014) Illuminated Fault 271
EF7 (000D) Flashing Alarm 288
EF7 (0015) Illuminated Fault 271
EF8 (000E) Flashing Alarm 289
EF8 (0016) Illuminated Fault 271
End1 Flashing Auto-Tuning Errors 301
End2 Flashing Auto-Tuning Errors 301
End3 Flashing Auto-Tuning Errors 301
End4 Flashing Auto-Tuning Errors 301
End5 Flashing Auto-Tuning Errors 301
End6 Flashing Auto-Tuning Errors 301
End7 Flashing Auto-Tuning Errors 301
EP24v (0081) Flashing Alarm 289
Er-01 Flashing Auto-Tuning Errors 301
