4.5 Keypad Operation
146 SIEPYEUOQ2A01G AC Drive Q2A Technical Manual
A - Serial Number
B - Rated Output Current (HD/ND)
C - Drive Software Version
D - Option A Information, and Option Software
Version
E - Option B Information: Not Installed
F - Option C Information, and Option Software
Version
G - Maximum Applicable Motor Output (HD/ND)
H - Drive Series
◆ Write Automatically Backed-up Parameters to the Drive
You can automatically back up parameters to the keypad connected to the drive and write those parameters to a
different drive as specified by the settings of o3-06 [AutoBackup Selection] and o3-07 [AutoBackup Lapse].
Note:
• Set o3-06 = 1 [AutoBackup Selection = Enabled] in each drive to which you will write the parameters.
• This operation is not available when the parameters in the keypad and the parameters on the other drives are set to the same values.
1. Connect the keypad to the drive.
The drive will ask to restore the parameters.
2. Push or to select [Yes] and then push .
3. Push or to select [Yes] and then push to confirm the restore process.
The keypad will show the “End” message when the write process is complete.
