11.19 Defaults by Drive Model and Duty Rating ND/HD
508 SIEPYEUOQ2A01G AC Drive Q2A Technical Manual
11.19 Defaults by Drive Model and Duty Rating ND/HD
The values for the parameters in these tables depend on the values for parameters o2-04 [Drive KVA Selection]
and C6-01 [ND/HD Duty Selection]. Changing the settings for o2-04 and C6-01 will change the default settings.
◆ 400 V Class
Parameters within parentheses are for motor 2.
Parameter Unit
Drive Model
4002 4004 4005 4007
C6-01 ND/HD Duty Selection -
HD ND HD ND HD ND HD ND
0 1 0 1 0 1 0 1
E2-11 Motor Rated Power (kW)
(E4-11 M2 Rated Power (kW))
kW 0.4 0.75 1.1 1.5 1.5 2.2 2.2 3.0
b3-04 SpSrch V/F Gain % 100 100 100 100 100 100 100 100
b3-06 Speed Curr Lev1 for Estimation - 0.5 0.5 0.5 0.5 0.5 0.5 0.5 0.5
b3-08 Speed ACR PGain for Estimation - 0.5 0.5 0.5 0.5 0.5 0.5 0.5 0.5
b3-26 Dir. Determ. Level - 1000 1000 1000 1000 1000 1000 1000 1000
b8-03 eSave Filter Time s 0.50 0.50 0.50 0.50 0.50 0.50 0.50 0.50
b8-04 eSave Coef. Value - 576.4 447.4 447.4 338.8 338.8 313.6 313.6 265.7
C5-17 Motor Inertia
(C5-37 M2 Inertia)
kgm
2
0.0015 0.0028 0.0028 0.0068 0.0068 0.0088 0.0088 0.0158
C6-02 Carrier Frequency Selection - 1 7 1 7 1 7 1 7
E2-01 Mot Rated Current (FLA)
(E4-01 M2 Rated Current (FLA))
A 1 1.6 1.6 3.1 3.1 4.2 4.2 5.7
E2-02 Mot Rated Slip
(E4-02 M2 Rated Slip)
Hz 2.9 2.6 2.6 2.5 2.5 3 3 2.7
E2-03 Mot No-Load Current
(E4-03 M2 No-Load Current)
A 0.6 0.8 0.8 1.4 1.4 1.5 1.5 1.9
E2-05 Motor L-L Resistance
(E4-05 M2 L-L Resistance)
Ω 38.198 22.459 22.459 10.1 10.1 6.495 6.495 4.360
E2-06 Motor Leak Inductance
(E4-06 M2 Leak Inductance)
% 18.2 14.3 14.3 18.3 18.3 18.7 18.7 19
E2-10 Motor Iron Loss
(E4-10 M2 Iron Loss)
W 14 26 26 53 53 77 77 105
E5-01 PM Mot Code Selection - 1232 1232 1233 1233 1235 1235 1236 1236
L2-02 RideThrough Time@Power Loss s 0.1 0.1 0.2 0.2 0.3 0.3 0.5 0.5
L2-03 Min Baseblck Time s 0.2 0.3 0.3 0.4 0.4 0.5 0.5 0.5
L2-04 Powloss Ramp Time@recovery s 0.3 0.3 0.3 0.3 0.3 0.3 0.3 0.3
L2-05 UV Detection Lvl (Uv1) - 380 380 380 380 380 380 380 380
L3-24 Acc@Rated Torque s 0.178 0.142 0.142 0.166 0.166 0.145 0.145 0.145
L8-02 Overheat Alm Level °C 100 100 105 105 112 112 110 110
L8-09 Ground Fault Selection - 1 1 1 1 1 1 1 1
L8-38 Carrier Reduction Mode - 2 2 2 2 2 2 2 2
n1-01 HuntPrev Selection - 1 1 1 1 1 1 1 1
n1-03 HuntPrev Time Constant ms 10 10 10 10 10 10 10 10
n1-16 HuntPrev HiFc Gain - 0.50 0.50 0.50 0.50 0.50 0.50 0.50 0.50
n5-02 Mot Inertia Acceleration Time s 0.178 0.142 0.142 0.166 0.166 0.145 0.145 0.145
n8-11 Observ.Calc Gain2 - 30.0 30.0 30.0 30.0 30.0 30.0 30.0 30.0
