Parameter List
11
11.19 Defaults by Drive Model and Duty Rating ND/HD
SIEPYEUOQ2A01G AC Drive Q2A Technical Manual 509
Parameter Unit
Drive Model
4009 4012 4018 4023
C6-01 ND/HD Duty Selection -
HD ND HD ND HD ND HD ND
0 1 0 1 0 1 0 1
E2-11 Motor Rated Power (kW)
(E4-11 M2 Rated Power (kW))
kW 3.0 4.0 4.0 5.5 5.5 7.5 7.5 11
b3-04 SpSrch V/F Gain % 100 100 100 100 100 100 100 100
b3-06 Speed Curr Lev1 for Estimation - 0.5 0.5 0.5 0.5 0.5 0.5 0.5 0.5
b3-08 Speed ACR PGain for Estimation - 0.5 0.5 0.5 0.5 0.5 0.5 0.5 0.5
b3-26 Dir. Determ. Level - 1000 1000 1000 1000 1000 1000 1000 1000
b8-03 eSave Filter Time s 0.50 0.50 0.50 0.50 0.50 0.50 0.50 0.50
b8-04 eSave Coef. Value - 265.7 245.8 245.8 189.5 189.5 145.38 145.38 140.88
C5-17 Motor Inertia
(C5-37 M2 Inertia)
kgm
2
0.0158 0.0158 0.0158 0.0255 0.026 0.037 0.037 0.053
C6-02 Carrier Frequency Selection - 1 7 1 7 1 7 1 7
E2-01 Mot Rated Current (FLA)
(E4-01 M2 Rated Current (FLA))
A 5.7 7 7 9.8 9.8 13.3 13.3 19.9
E2-02 Mot Rated Slip
(E4-02 M2 Rated Slip)
Hz 2.7 2.7 2.7 1.5 1.5 1.3 1.3 1.7
E2-03 Mot No-Load Current
(E4-03 M2 No-Load Current)
A 1.9 2.3 2.3 2.6 2.6 4 4 5.6
E2-05 Motor L-L Resistance
(E4-05 M2 L-L Resistance)
Ω 4.360 3.333 3.333 1.595 1.595 1.152 1.152 0.922
E2-06 Motor Leak Inductance
(E4-06 M2 Leak Inductance)
% 19 19.3 19.3 18.2 18.2 15.5 15.5 19.6
E2-10 Motor Iron Loss
(E4-10 M2 Iron Loss)
W 105 130 130 193 193 263 263 385
E5-01 PM Mot Code Selection - FFFF FFFF 1238 1238 123A 123A 123B 123B
L2-02 RideThrough Time@Power Loss s 0.5 0.5 0.5 0.5 0.8 0.8 1 1
L2-03 Min Baseblck Time s 0.5 0.6 0.6 0.7 0.7 0.8 0.8 0.9
L2-04 Powloss Ramp Time@recovery s 0.3 0.3 0.3 0.3 0.3 0.3 0.3 0.3
L2-05 UV Detection Lvl (Uv1) - 380 380 380 380 380 380 380 380
L3-24 Acc@Rated Torque s 0.145 0.154 0.154 0.168 0.168 0.175 0.175 0.265
L8-02 Overheat Alm Level °C 100 100 100 100 105 105 105 105
L8-09 Ground Fault Selection - 1 1 1 1 1 1 1 1
L8-38 Carrier Reduction Mode - 2 2 2 2 2 2 2 2
n1-01 HuntPrev Selection - 1 1 1 1 1 1 1 1
n1-03 HuntPrev Time Constant ms 10 10 10 10 10 10 10 10
n1-16 HuntPrev HiFc Gain - 0.50 0.50 0.50 0.50 0.50 0.50 0.50 0.50
n5-02 Mot Inertia Acceleration Time s 0.145 0.154 0.154 0.168 0.168 0.175 0.175 0.265
n8-11 Observ.Calc Gain2 - 30.0 30.0 30.0 30.0 30.0 30.0 30.0 30.0
Parameter Unit
Drive Model
4031 4038 4044 4060
C6-01 ND/HD Duty Selection -
HD ND HD ND HD ND HD ND
0 1 0 1 0 1 0 1
E2-11 Motor Rated Power (kW)
(E4-11 M2 Rated Power (kW))
kW 11 15 15 18.5 18.5 22 22 30
b3-04 SpSrch V/F Gain % 100 100 100 100 100 100 100 100
b3-06 Speed Curr Lev1 for Estimation - 0.5 0.5 0.5 0.5 0.5 0.5 0.5 0.5
b3-08 Speed ACR PGain for Estimation - 0.5 0.5 0.5 0.5 0.5 0.5 0.5 0.5
b3-26 Dir. Determ. Level - 1000 1000 1000 1000 1000 1000 1000 1000
