Parameter List
11
11.8 H: TERMINALS
SIEPYEUOQ2A01G AC Drive Q2A Technical Manual 461
Setting Function Description Ref.
D GenerTrqLim
Enters the torque limit that is the same for all quadrants for forward, reverse, and regenerative operation if the
motor rated torque is 100%.
741
E OvUntrq Level
Enters a signal to adjust the overtorque/undertorque detection level.
Note:
Use this function with L6-01 [Trq Det1 Select]. This parameter functions as an alternative to L6-02 [Trq Det1
Level].
741
F PID Fbk
Enters the PID feedback value.
742
10 PID SetPoint
Enters the PID setpoint.
742
11 Diff PIDFbk
Enters the PID differential feedback value if the full scale analog signal (10 Vor 20 mA) is 100%.
742
12 AcDcTimeGain
Enters a signal to adjust the gain used for C1-01 to C1-08 [Accel Time 1 to Decel Time 4] if the full scale analog
signal (10 Vor 20 mA) is 100%.
742
13 DCInjBrakCurr
Enters a signal to adjust the current level used for DC Injection Braking if the drive rated output current is 100%.
742
14 StallPLev@Rn
Enters a signal to adjust the stall prevention level during run if the drive rated current is 100%.
743
15 OutFLowLimSel
Enters a signal to adjust the output frequency lower limit level if E1-04 [Max Output Frequency] = 100%.
743
16 Mot PTC Input
Uses the motor Positive Temperature Coefficient (PTC) thermistor to prevent heat damage to the motor if the
current value when the 10 V (or 20 mA) analog signal is input is 100%.
743
30 Q2pack AI1
Use with Q2pack. Refer to the Q2pack online manual for more information.
743
31 Q2pack AI2
Use with Q2pack. Refer to the Q2pack online manual for more information.
743
32 Q2pack AI3
Use with Q2pack. Refer to the Q2pack online manual for more information.
744
33 Q2pack AI4
Use with Q2pack. Refer to the Q2pack online manual for more information.
744
34 Q2pack AI5
Use with Q2pack. Refer to the Q2pack online manual for more information.
744
35 Q2pack AI6
Use with Q2pack. Refer to the Q2pack online manual for more information.
744
◆ H4: ANALOG OUTPUTS
No.
(Hex.)
Name Description
Default
(Range)
Ref.
H4-01
(041D)
AO1 An.Out Select
Sets the monitor number to send from MFAO terminal AO1.
Set the x-xx part of the U: MONITORS. For example, set H4-01 = 102 to monitor U1-02
[Output Frequency].
102
(000 - 999)
745
H4-02
(041E)
RUN
AO1 An.Out Gain
Sets the gain of the monitor signal that is sent from MFAO terminal AO1.
Sets the analog signal output level from the terminal AO1 at 10 Vor 20 mA as 100%
when an output for monitoring items is 100%.
100.0%
(-999.9 - +999.9%)
746
H4-03
(041F)
RUN
AO1 An.Out Bias
Sets the bias of the monitor signal that is sent from MFAO terminal AO1.
Set the level of the analog signal sent from terminal AO1 at 10 Vor 20 mA as 100%
when an output for monitoring items is 0%.
0.0%
(-999.9 - +999.9%)
746
H4-04
(0420)
AO2 An.Out Select
Sets the monitoring number to be output from the MFAO terminal AO2.
Set the x-xx part of the U: MONITORS. For example, set H4-04 to 102 to monitor U1-
02 [Output Frequency].
103
(000 - 999)
746
H4-05
(0421)
RUN
AO2 An.Out Gain
Sets the gain of the monitor signal that is sent from MFAO terminal AO2.
When an output for monitoring items is 0%, this parameter sets the analog signal output
level from the AO2 terminal at 10 Vor 20 mA as 100%.
50.0%
(-999.9 - +999.9%)
746
