Q2 Q2A User Manual

Startup Procedure and Test Run
4
4.2 User Interface Elements
SIEPYEUOQ2A01G AC Drive Q2A Technical Manual 125
Sym
bol
Name Description
E
Frequency reference
source indicator
Shows the current frequency reference source.
• KPD: keypad
• AI: analog input terminal (terminals AI1 to AI3)
• COM: Modbus communications
• OPT: option card
• PI: pulse train input terminal (terminal PI)
F Data display area
Shows parameter values, monitor values, and details of the results of operations.
G
Function keys 1 to 3 (F1
to F3)
The function names shown in this area will change when the selected screen changes. Push one of the function keys to
on the keypad to do the function.
◆ Keypad Mode and Menu Displays
Note:
• Push to set d1-01 [Reference 1] when the screen MONITORS shows U1-01 [Frequency Reference] in LOCAL Mode.
• The keypad will show [Rdy] when the drive is in Drive Mode. The drive is prepared to accept a Run command.
• The drive will not accept a Run command in Programming Mode in the default setting. Set b1-08 [RUN@PRG Mode Selection] to
accept or reject a Run command from an external source while in Programming Mode.
–Set b1-08 = 1 [NoRUN@Program] to reject the Run command from an external source while in Programming Mode (default).
–Set b1-08 = 2 [RUN@Program] to accept the Run command from an external source while in Programming Mode.
–Set b1-08 = 3 [Program@Stop only] to prevent changes from Drive Mode to Programming Mode while the drive is operating.
Table 4.3 Drive Modes, Menu Screens and Functions
Mode Menu Screen Function
Drive Mode MONITORS
Sets monitor items to display.
Programming Mode
AUTOTUNING
Auto-Tunes the drive.
INITIALIZATION
Changes initial settings.
APPLICATION
Changes application settings.
TUNING
Changes tuning settings.
REFERENCE
Changes reference settings.
MOTOR
Changes motor settings.
OPTIONS
Changes external options settings.
TERMINALS
Changes terminals settings.
PROTECTION
Changes protection settings.
SPECIAL
Changes settings for special applications.
KEYPAD
Changes keypad settings.
Q2PACK PARAMETERS
Changes parameters of Q2Pack software.
Q2PACK JOINTS
Changes joints of Q2Pack software.
