Specifications
10
10.5 Drive Derating
SIEPYEUOQ2A01G AC Drive Q2A Technical Manual 377
Model
Rated Current (A)
Heavy Duty Rating (HD2) Normal Duty Rating (ND2)
2 kHz 5 kHz 8 kHz 10 kHz 12.5 kHz 15 kHz 2 kHz 5 kHz 8 kHz 10 kHz 12.5 kHz 15 kHz
4568
477.0 397.5 - - - - 515 397 - - - -
4675
- - - - - - - - - - - -
◆ Carrier Frequency Settings and Rated Current Values when Using PM
Advanced Open Loop Vector Control Method
The following tables show how the drive rated output current changes when C6-02 [Carrier Frequency Selection]
value changes, and when A1-02 = 6 [Control Method = PM AOLVector]. The output current value changes
linearly as the carrier frequency changes. You can use the values from the tables to calculate a frequency that is
not shown.
■ 200 V Class
Table 10.16 AOLV/PM Carrier Frequency and Rated Current Derating
Model
Rated Current (A)
Heavy Duty Rating (HD1) Normal Duty Rating (ND1)
2 kHz 4 kHz 6 kHz 8 kHz 10 kHz 12 kHz 2 kHz 4 kHz 6 kHz 8 kHz 10 kHz 12 kHz
2004 3.2 3.2 3.1 3.0 2.8 2.6 3.5 3.1 2.8 2.4 2.1 1.7
2006 5.0 5.0 4.9 4.6 4.3 4.1 6.0 5.4 4.8 4.2 3.6 3.0
2010 8.0 8.0 7.7 6.7 5.8 4.8 9.6 8.6 7.7 6.7 5.8 4.8
2012 11.0 11.0 10.7 9.8 8.8 7.9 12.2 11.5 10.7 10.0 9.3 8.6
2018 14.0 14.0 13.3 11.2 9.1 6.9 17.5 15.4 13.3 11.2 9.1 6.9
2021 17.5 17.5 16.8 14.7 12.6 10.4 21.0 18.9 16.8 14.6 12.5 10.4
2030 25.0 25.0 24.0 21.0 18.0 15.0 30.0 27.0 24.0 21.0 18.0 15.0
2042 33.0 33.0 31.2 25.7 20.2 14.7 42.0 36.6 31.2 25.8 20.4 15.0
2056 47.0 47.0 45.2 39.8 34.4 29.0 56.0 50.6 45.2 39.8 34.4 29.0
2070 60.0 60.0 58.0 52.0 46.0 40.0 70.0 64.0 58.0 52.0 46.0 40.0
2082 75.0 75.0 71.8 62.1 52.5 42.9 82.0 81.4 72.0 62.6 53.1 43.7
2110 88.0 88.0 84.2 72.9 61.6 50.3 110.0 99.0 88.0 77.0 66.0 55.0
2138 115.0 115.0 110.1 95.3 80.5 65.7 138.0 124.2 110.4 96.6 82.8 69.0
2169 145.0 138.4 118.6 98.8 78.9 - 169.0 144.6 120.1 95.7 71.2 -
2211 180.0 171.7 146.9 122.0 97.2 - 211.0 179.7 148.5 117.2 86.0 -
2257 215.0 204.9 174.7 144.5 114.3 - 257.0 217.1 177.2 137.3 97.4 -
2313 283.0 271.7 237.7 203.8 169.8 - 313.0 276.2 239.4 202.6 165.8 -
2360 346.0 328.8 277.0 225.3 173.6 - 359.6 316.4 273.2 230.0 186.8 -
2415 415.0 398.4 348.6 298.8 249.0 - - - - - - -
■ 400 V Class
Table 10.17 AOLV/PM Carrier Frequency and Rated Current Derating (< 460 V)
Model
Rated Current (A)
Heavy Duty Rating (HD1) Normal Duty Rating (ND1)
2 kHz 4 kHz 6 kHz 8 kHz 10 kHz 12 kHz 2 kHz 4 kHz 6 kHz 8 kHz 10 kHz 12 kHz
4002
1.8 1.8 1.7 1.3 1.0 0.6 2.1 1.9 1.7 1.6 1.4 1.2
4004
3.4 3.4 3.2 2.4 1.7 1.0 4.1 3.7 3.3 2.8 2.4 2.0
4005
4.8 4.8 4.5 3.8 3.0 2.3 5.4 5.0 4.7 4.3 3.9 3.6
4007
5.5 5.5 5.2 4.2 3.2 2.3 7.1 6.1 5.2 4.2 3.2 2.3
4009
7.2 7.2 6.9 5.8 4.8 3.8 8.9 7.9 6.8 5.8 4.8 3.7
