10.5 Drive Derating
378 SIEPYEUOQ2A01G AC Drive Q2A Technical Manual
Model
Rated Current (A)
Heavy Duty Rating (HD1) Normal Duty Rating (ND1)
2 kHz 4 kHz 6 kHz 8 kHz 10 kHz 12 kHz 2 kHz 4 kHz 6 kHz 8 kHz 10 kHz 12 kHz
4012
9.2 9.2 8.7 7.0 5.4 3.8 11.9 10.3 8.6 7.0 5.4 3.8
4018
14.8 14.8 14.0 11.4 8.9 6.3 17.5 16.5 14.0 11.4 8.9 6.3
4023
18.0 18.0 17.0 13.9 10.8 7.7 23.4 20.4 17.3 14.1 11.0 7.8
4031
24.0 24.0 22.6 18.4 14.1 9.9 31.0 26.8 22.6 18.3 14.1 9.9
4038
31.0 31.0 29.2 23.9 18.6 13.3 38.0 34.5 29.2 23.9 18.6 13.3
4044
39.0 39.0 36.8 30.1 23.4 16.7 44.0 41.6 35.5 29.5 23.4 17.3
4060
45.0 45.0 42.1 33.3 24.4 15.6 59.6 50.8 42.0 33.2 24.4 15.6
4075
60.0 60.0 56.6 46.3 36.0 25.7 74.9 70.2 59.3 48.4 37.5 26.5
4089
75.0 75.0 70.7 57.9 45.0 32.1 89.2 84.5 71.5 58.6 45.6 32.7
4103
91.0 91.0 85.8 70.2 54.6 39.0 103.0 100.5 85.2 69.9 54.6 39.3
4140
112.0 105.3 85.1 65.0 44.8 - 140.0 114.1 88.1 62.0 36.0 -
4168
150.0 141.0 114.0 87.0 60.0 - 168.0 141.8 115.6 89.5 63.3 -
4208
180.0 169.2 136.8 104.4 72.0 - 208.0 165.5 123.1 80.6 38.1 -
4250
216.0 203.0 164.2 125.3 86.4 - 250.0 207.7 165.3 123.0 80.6 -
4296
260.0 244.4 197.6 150.8 104.0 - 296.0 247.1 198.3 149.4 100.6 -
4371
304.0 285.8 231.0 176.3 121.6 - 371.0 305.3 239.7 174.0 108.3 -
4389
371.0 348.7 282.0 215.2 148.4 - 389.0 327.5 265.7 203.8 142.0 -
4453
389.0 292.5 - - - - 453.0 296.7 - - - -
4568
453.0 340.7 - - - - 568.0 372.0 - - - -
4675
605.0 455.0 - - - - 675.0 455.0 - - - -
Table 10.18 AOLV/PM Carrier Frequency and Rated Current Derating (≥ 460 V)
Model
Rated Current (A)
Heavy Duty Rating (HD2) Normal Duty Rating (ND2)
2 kHz 4 kHz 6 kHz 8 kHz 10 kHz 12 kHz 2 kHz 4 kHz 6 kHz 8 kHz 10 kHz 12 kHz
4002
2.1 1.8 1.5 1.2 0.9 0.6 2.1 1.9 1.7 1.6 1.4 1.2
4004
2.8 2.4 2.0 1.5 1.1 0.6 3.0 2.7 2.4 2.1 1.8 1.5
4005
4.3 3.8 3.2 2.7 2.2 1.6 4.8 4.5 4.2 3.8 3.5 3.2
4007
6.2 5.4 4.5 3.7 2.8 2.0 6.9 6.0 5.0 4.1 3.2 2.2
4009
8.6 7.6 6.6 5.6 4.6 3.6 7.6 6.7 5.8 5.0 4.1 3.2
4012
9.8 8.5 7.2 5.8 4.5 3.1 11.0 9.5 8.0 6.5 5.0 3.5
4018
14.1 12.3 10.4 8.5 6.6 4.7 15.2 13.2 11.2 9.1 7.1 5.1
4023
18.0 15.6 13.2 10.8 8.4 6.0 21.0 18.3 15.5 12.7 9.9 7.0
4031
27.2 23.5 19.8 16.1 12.4 8.7 27.0 23.3 19.6 16.0 12.3 8.6
4038
34.7 30.1 25.5 20.8 16.2 11.6 34.0 30.9 26.2 21.4 16.6 11.9
4044
34.0 34.0 32.1 26.2 20.4 14.6 40.0 37.8 32.3 26.8 21.3 15.8
4060
40.0 40.0 37.4 29.6 21.7 13.9 52.0 44.3 36.7 29.0 21.3 13.6
4075
52.0 52.0 49.0 40.1 31.2 22.3 65.0 60.9 51.4 42.0 32.5 23.0
4089
65.0 65.0 61.3 50.1 39.0 27.9 77.0 72.9 61.7 50.6 39.4 28.2
4103
77.0 77.0 72.6 59.4 46.2 33.0 96.0 93.6 79.4 65.1 50.9 36.6
4140
96.0 90.2 73.0 55.7 38.4 - 124.0 101.1 78.0 54.9 31.9 -
4168
124.0 116.6 94.2 71.9 49.6 - 156.0 131.7 107.4 83.1 58.8 -
4208
156.0 146.6 118.6 90.5 62.4 - 180.0 143.2 106.5 69.7 33.0 -
4250
180.0 169.2 136.8 104.4 72.0 - 240.0 199.4 158.7 118.1 77.4 -
4296
240.0 225.6 182.4 139.2 96.0 - 302.0 252.2 202.3 152.5 102.6 -
