10.3 Model Specifications (400 V Class)
366 SIEPYEUOQ2A01G AC Drive Q2A Technical Manual
10.3 Model Specifications (400 V Class)
Table 10.5 Rating (400 V Class)
Model
Input
Voltage
Duty
Rating
4002 4004 4005 4007 4009 4012 4018 4023
Maximum Applicable
Motor Output (kW)
< 460 V
*1
HD 0.55 0.75 1.5 2.2 3 3.7 5.5 7.5
ND 0.75 1.5 2.2 3 3.7 5.5 7.5 11
≧ 460 V
*2
HD 0.55 0.75 1.5 2.2 3 3.7 5.5 7.5
ND 0.75 1.5 2.2 3 3.7 5.5 7.5 11
Maximum Applicable
Motor Output (HP)
< 460 V
*1
HD 3/4 1 2 3 4 5 7 1/2 10
ND 1 2 3 4 5 7 1/2 10 15
≧ 460 V
*2
HD 3/4 1 2 3 4 5 7 1/2 10
ND 1 2 3 4 5 7 1/2 10 15
Input
Rated Input
Current (A)
*3
< 460 V
HD (AC) 1.9 3.5 4.7 6.7 8.9 11.7 15.8 21.2
HD (DC) 2.3 4.3 5.8 8.2 11 15 20 26
ND (AC) 2.5 4.7 6.7 8.9 11.7 15.8 21.2 30.6
ND (DC) 3.1 5.8 8.2 11 15 20 26 38
≥ 460 V
HD (AC) 1.6 2.1 3.9 5.5 7.4 9.0 13.1 17.5
HD (DC) 1.9 2.5 4.8 6.8 9.0 11 16 22
ND (AC) 2.1 3.9 5.5 7.4 9.0 13.1 17.5 25.3
ND (DC) 2.5 4.8 6.8 9.0 11 16 22 31
Outputs
Rated Output
Capacity
(kVA)
< 460 V
*4
HD 1.2 2.2 3.2 3.6 4.7 6.1 10 12
ND 1.4 2.7 3.6 4.7 5.9 7.8 12 15
≧ 460 V
*5
HD 1.3 1.7 2.7 3.8 5.5 6.1 8.8 11
ND 1.7 2.4 3.8 5.5 6.1 8.8 11 17
Rated Output
Current (A)
< 460 V
HD 1.8 3.4 4.8 5.5 7.2 9.2 14.8 18
ND 2.1 4.1 5.4 7.1 8.9 11.9 17.5 23.4
≥ 460 V
HD 1.6 2.1 3.4 4.8 6.9 7.6 11 14
ND 2.1 3 4.8 6.9 7.6 11 14 21
Overload Tolerance
• HD: 150% of the rated output current for 60 seconds
• ND: 110% of the rated output current for 60 seconds
Note:
Derating may be necessary for applications that start and stop frequently.
Carrier Frequency
HD: 8 kHz without derating the drive capacity.
ND: 2 kHz without derating the drive capacity.
Derate the drive capacity to use values to 15 kHz maximum.
Maximum Output Voltage
Three-phase 380 V to 480 V
Note:
The maximum output voltage is proportional to the input voltage.
Maximum Output Frequency
• Advanced Open Loop Vector Control (AOLV) and EZ Open Loop Vector Control (EZOLV): 120 Hz
• Closed Loop V/f Control (CL-V/f), Closed Loop Vector Control (CLV), Advanced Open Loop Vector Control for
PM (AOLV/PM), and Closed Loop Vector Control for PM (CLV/PM): 400 Hz
• V/f Control (V/f), Open Loop Vector Control (OLV), and Open Loop Vector Control for PM (OLV/PM): 590 Hz
Measures for
Harmonics
DC Reactor External options
Braking
Device
Braking Transistor Standard internal characteristics
EMC Filter
EMC Filter
IEC61800-3, C3
There is a category C3 EMC filter in the drive.
