Specifications
10
10.2 Model Specifications (200 V Class)
SIEPYEUOQ2A01G AC Drive Q2A Technical Manual 365
Model 2169 2211 2257 2313 2360 2415
Output
Rated Output
Capacity (kVA)
HD1
*3
55.3 68.6 81.9 108 132 158
ND1
*4
64.4 80.4 97.9 119 137 -
Rated Output
Current (A)
HD1 145 180 215 283 346 415
ND1 169 211 257 313 360 -
Overload Tolerance
• HD: 150% of the rated output current for 60 seconds The permitted frequency of overload is once every 10
minutes.
• ND: 110% of the rated output current for 60 seconds The permitted frequency of overload is once every 10
minutes.
Note:
Derating may be necessary for applications that start and stop frequently.
Carrier Frequency
HD1: 5 kHz without derating the drive capacity.
ND: 2 kHz without derating the drive capacity.
Derate the drive capacity to use values to 10 kHz maximum.
Maximum Output Voltage
Three-phase 200 V to 240 V
Note:
The maximum output voltage is proportional to the input voltage.
Maximum Output Frequency
• Advanced Open Loop Vector Control (AOLV) and EZ Open Loop Vector Control (EZOLV): 120 Hz
• Closed Loop V/f Control (CL-V/f), Closed Loop Vector Control (CLV), Advanced Open Loop Vector Control for
PM (AOLV/PM), and Closed Loop Vector Control for PM (CLV/PM): 400 Hz
• V/f Control (V/f), Open Loop Vector Control (OLV), and Open Loop Vector Control for PM (OLV/PM): 590 Hz
Measures for
Harmonics
DC reactor Standard internal characteristics
Braking Device Braking Transistor External options
EMC Filter
EMC Filter
IEC61800-3, C2/C3
Factory option
• Models 2xxxB: There is a category C3 EMC filter in the drive.
• Models 2xxxC: There is a category C2 EMC filter in the drive.
Power Supply
Rated Voltage/Rated Frequency
• Three-phase AC power supply 200 V to 240 V at 50/60 Hz
• DC power supply 270 V to 340 V
Permitted Voltage Fluctuation -15% to +10%
Permitted Frequency Fluctuation ±5%
Input Power
(kVA)
HD1 56.5 68.2 83.1 113 135 164
ND1 68.2 83.1 113 135 164 -
*1 The maximum applicable motor output complies with 208 V motor ratings as specified in NEC Table 430.250. The rated output
current of the drive output amps must be equal to or more than the motor rated current.
*2 The maximum applicable motor output is based on 4-pole, general-purpose 220 V motor ratings. The rated output current of the drive
output amps must be equal to or more than the motor rated current.
*3 The rated output capacity is calculated with a rated output voltage of 208 V.
*4 The rated output capacity is calculated with a rated output voltage of 220 V.
