12.5 E: MOTOR
636 SIEPYEUOQ2A01G AC Drive Q2A Technical Manual
■ E1-08 Mid A Voltage
No.
(Hex.)
Name Description
Default
(Range)
E1-08
(0307)
Mid A Voltage
Sets a middle output voltage for the V/f pattern.
Determined by A1-02，C6-
01 and o2-04
(400 V Class: 0.0 to 510.0
V)
Note:
Default setting is determined by A1-02 [Control Method], C6-01 [ND/HD Duty Selection], and o2-04 [Drive KVA Selection].
■ E1-09 Min Output Frequency
No.
(Hex.)
Name Description
Default
(Range)
E1-09
(0308)
Min Output Frequency
Sets the minimum output frequency for the V/f pattern.
Determined by A1-02 and
E5-01
(Determined by A1-02, E1-
04, and E5-01)
■ E1-10 Min Output Voltage
No.
(Hex.)
Name Description
Default
(Range)
E1-10
(0309)
Min Output Voltage
Sets the minimum output voltage for the V/f pattern.
Determined by A1-02
■ E1-11 Mid B Frequency
No.
(Hex.)
Name Description
Default
(Range)
E1-11
(030A)
Expert
Mid B Frequency
Sets a middle output frequency for the V/f pattern.
0.0 Hz
(0.0 - E1-04)
Note:
Set this parameter to 0.0 to disable the function.
■ E1-12 Min Output Voltage
No.
(Hex.)
Name Description
Default
(Range)
E1-12
(030B)
Expert
Min Output Voltage
Sets minimum output voltage for the V/f pattern.
0.0 V
Note:
Set this parameter to 0.0 to disable the function.
■ E1-13 Base Voltage
No.
(Hex.)
Name Description
Default
(Range)
E1-13
(030C)
Expert
Base Voltage
Sets the base voltage for the V/f pattern.
0.0 V
Note:
• The setting value of E1-13 = E1-05 [Max Output Voltage] after you do Auto-Tuning.
• When E1-13 = 0.0, use the value of E1-05 to control the voltage.
◆ E2: MOTOR 1 PARAMETERS
E2 parameters are used to set induction motor data. To switch drive operation from one motor to another motor,
configure the first motor (motor 1).
Performing Auto-Tuning automatically sets the E2 parameters to the optimal values. If Auto-Tuning cannot be
performed, set the E2 parameters manually.
