Parameter List
11
11.7 F: OPTIONS
SIEPYEUOQ2A01G AC Drive Q2A Technical Manual 439
No.
(Hex.)
Name Description
Default
(Range)
Ref.
F1-51
(03D3)
PGoH Detect Level
The drive will detect PGoH [Encoder (PG) Hardware Fault] when the value of this
parameter is less than the value of .
Note:
Set F1-20 = 1 [Enc1 PCB Disconnect Detect = Enabled] to enable this function.
80%
(1 - 100%)
656
F1-52
(03D4)
Serial Enc bps for
Communication
Sets the communication speed between the PG-F3 option and the serial encoder.
0 : 1M/9600bps
1 : 500k/19200bps
2 : 1M/38400bps
0
(0 - 2)
656
◆ F2: ANALOG INPUT
No.
(Hex.)
Name Description
Default
(Range)
Ref.
F2-01
(038F)
An.In Funct.Selection
Sets the input method for the analog reference used with AI-A3.
0 : 3 Independent Channels
1 : 3 Channels Added Together
0
(0, 1)
656
F2-02
(0368)
RUN
An.In Option Gain
Sets the analog reference gain as a percentage when the maximum output frequency is
100%.
Note:
Set F2-01 = 1 [An.In Funct.Selection = 3 Channels Added Together] to enable this
function.
100.0%
(-999.9 - +999.9%)
658
F2-03
(0369)
RUN
An.In Option Bias
Sets the analog reference bias as a percentage when the maximum output frequency is
100%.
Note:
Set F2-01 = 1 [An.In Funct.Selection = 3 Channels Added Together] to enable this
function.
0.0%
(-999.9 - +999.9%)
658
◆ F3: DIGITAL INPUT
No.
(Hex.)
Name Description
Default
(Range)
Ref.
F3-01
(0390)
D.In Funct Selection
Sets the data format of digital input signals. Set o1-03 = 0 or 1 [FrqDisplay Unit
Selection = 0.01 Hz or 0.01% (100%=E1-04)] to enable this function.
Note:
The input signal type is BCD when o1-03 = 2 or 3 [rpmor User-selected units]. The
o1-03 value sets the setting units.
0 : BCD, 1% units
1 : BCD, 0.1% units
2 : BCD, 0.01% units
3 : BCD, 1 Hz units
4 : BCD, 0.1 Hz units
5 : BCD, 0.01 Hz units
6 : BCD (5-digit), 0.01 Hz
7 : Binary Input
8 : MF Digital Input
0
(0 - 8)
658
F3-03
(03B9)
D.In Data Length Select
Sets the number of bits to set the frequency reference with DI-A3.
0 : 8-bit
1 : 12-bit
2 : 16-bit
2
(0 - 2)
659
F3-10
(0BE3)
Expert
D0 Function Selection
Sets the function for terminal D0 of the DI-A3 when F3-01 = 8 [D.In Funct Selection =
MF Digital Input].
0
(0 - 4, 6 - 19F)
660
F3-11
(0BE4)
Expert
D1 Function Selection
Sets the function for terminal D1 of the DI-A3 when F3-01 = 8 [D.In Funct Selection =
MF Digital Input].
0
(0 - 4, 6 - 19F)
660
F3-12
(0BE5)
Expert
D2 Function Selection
Sets the function for terminal D2 of the DI-A3 when F3-01 = 8 [D.In Funct Selection =
MF Digital Input].
0
(0 - 4, 6 - 19F)
661
