Parameter Details
12
12.6 F: OPTIONS
SIEPYEUOQ2A01G AC Drive Q2A Technical Manual 659
2 : BCD, 0.01% units
3 : BCD, 1 Hz units
4 : BCD, 0.1 Hz units
5 : BCD, 0.01 Hz units
6 : BCD (5-digit), 0.01 Hz
7 : Binary Input
The setting unit and setting range vary depending on the value set in F3-03 [D.In Data Length Select].
• F3-03 = 0 [8-bit]: 100%/255 (-255 to +255)
• F3-03 = 1 [12-bit]: 100%/4095 (-4095 to +4095)
• F3-03 = 2 [16-bit]: 100%/30000 (-33000 to +33000)
8 : MF Digital Input
The DI-A3 card is also used as a multi-function digital input terminal.
■ F3-03 D.In Data Length Select
No.
(Hex.)
Name Description
Default
(Range)
F3-03
(03B9)
D.In Data Length Select
Sets the number of bits to set the frequency reference with DI-A3.
2
(0 - 2)
0 : 8-bit
1 : 12-bit
2 : 16-bit
V/f
CL-V/f
OLV
CLV
AOLV
OLV/PM OLV/PM
AOLV/PM
CLV/PM
EZOLV
