10.7 Leakage Current for Built-in Filter
384 SIEPYEUOQ2A01G AC Drive Q2A Technical Manual
10.7 Leakage Current for Built-in Filter
This chapter shows the embedded C3 EMC filter leakage current.
◆ 200 V Class
Model
Leakage Current
mA
2004
18.2
2006
18.2
2010
18.2
2012
18.2
2018
18.2
2021
18.2
2030
18.2
2042
18.2
2056
18.2
2070
74.7
Model
Leakage Current
mA
2082
74.7
2110
78.1
2138
85.1
2169
85.1
2211
85.1
2257
98.4
2313
98.4
2360
98.4
2415 98.4
◆ 400 V Class
Model
Leakage Current
mA
4002
36.3
4004
36.3
4005
36.3
4007
36.3
4009
36.3
4012
36.3
4018
36.3
4023
36.3
4031
36.3
4038
36.3
4044
149.3
4060
149.3
4075
149.3
Model
Leakage Current
mA
4089
170.3
4103
170.3
4140
170.3
4168
170.3
4208
196.6
4250
196.6
4296
196.6
4371
196.6
4389
196.6
4453
196.6
4568
196.6
4675
196.6
