5.2 European Standards
190 SIEPYEUOQ2A01G AC Drive Q2A Technical Manual
Drive Model
Fuse
Manufacturer: Bussmann
Model Quantity
4007 FWH-60B 2
4009 FWH-60B 2
4012 FWH-60B 2
4018 FWH-80B 2
4023 FWH-90B 2
4031 FWH-150B 2
4038 FWH-200B 2
4044 FWH-200B 2
4060 FWH-225A 2
4075 FWH-250A 2
4089 FWH-275A 2
4103 FWH-275A 2
4140
FWH-300A
FWH-325A
*1
2
4168
FWH-400A
FWH-450A
*1
2
4208
FWH-500A
FWH-600A
*1
2
4250
FWH-600A
FWH-700A
*1
2
4296
FWH-700A
FWH-800A
*1
2
4371
FWH-800A
FWH-1000A
*1
2
4389
FWH-1000A
FWH-1200A
*1
2
4453
FWH-1200A
FWH-1400A
*1
2
4568
FWH-1200A
FWH-1600A
*1
2
4675 FWH-1600A 2
*1 A fuse with a large rated current for applications with repeated loads is recommended.
◆ EMC Directive
Drives with built-in EMC filters (models 2xxxB, 2xxxC, 4xxxB, 4xxxC) were tested in accordance with European
standard IEC/EN 61800-3:2004/A1:2012, and comply with the EMC Directive.
Use drives with built-in EMC filters or install external EMC filters to the drive input side to comply with the
EMC Directive. Refer to Installing the External EMC Noise Filter on page 196 for the installation of the EMC
filter.
■ Install a Drive to Conform to the EMC Directive
Install drives with this procedure to comply with the EMC Directive when the drive is a single unit or installed in
a larger device.
1. Install the drive on a grounded metal plate.
2. Wire the drive and motor.
