12.6 F: OPTIONS
658 SIEPYEUOQ2A01G AC Drive Q2A Technical Manual
■ F2-02 An.In Option Gain
No.
(Hex.)
Name Description
Default
(Range)
F2-02
(0368)
RUN
An.In Option Gain
Sets the analog reference gain as a percentage when the maximum output frequency is 100%.
100.0%
(-999.9 - +999.9%)
Note:
Set F2-01 = 1 [An.In Funct.Selection = 3 Channels Added Together] to enable this function.
■ F2-03 An.In Option Bias
No.
(Hex.)
Name Description
Default
(Range)
F2-03
(0369)
RUN
An.In Option Bias
Sets the analog reference bias as a percentage when the maximum output frequency is 100%.
0.0%
(-999.9 - +999.9%)
Note:
Set F2-01 = 1 [An.In Funct.Selection = 3 Channels Added Together] to enable this function.
◆ F3: DIGITAL INPUT
F3 parameters set the type of input signal to use with digital input option card DI-A3.
Use these digital inputs to set the frequency reference when you install the DI-A3 card in a drive. Set b1-01 = 3
[Freq. Ref. Sel. 1 = Option PCB] to use this card as the frequency reference input. The input signal is isolated
input of 24 Vdc and 8 mA.
• Binary, 16-bit/BCD, 4-digit input
• Binary, 12-bit/BCD, 3-digit input
• Binary, 8-bit/BCD, 2-digit input
You can also use the DI-A3 card as an MFDI, if the setting of F3-01 is correct.
WARNING! Sudden Movement Hazard. Do test runs and examine the drive to make sure that command references are
configured correctly. If you set the command reference incorrectly, it can cause death, serious injury, or equipment damage from
unwanted motor rotation.
■ DI for DI-A3
Set F3-01 = 8 [D.In Funct Selection = MF Digital Input] and b1-01 ≠ 3 [Freq. Ref. Sel. 1 ≠ Option PCB] to use
digital input option DI-A3 as an DI.
Use F3-10 to F3-25 [D0 Function Selection to DF Function Selection] to set the function for the DI-A3 terminals.
Note:
• Refer to H1-xx “Multi-function Digital Input Setting Values” for more information about DI setting values.
• Values 0 [3-Wire Sequence] and 20 to 2F [External Fault] for F3-10 to F3-25.
• When you do not use DI-A3 as an DI, set F3-10 to F3-25 = F [Not Used].
• The drive reads DI-A3 terminal Dx two times as specified by parameter b1-06 [Double Scan DI Inputs Select].
• Configuring such that F3-01 = 8 when DI-A3 is the frequency reference source (b1-01 or b1-15 = 3 [Freq. Ref. Sel. 1 or Freq. Ref.
Sel. 2 = Option PCB]) results in the detection of oPE05 [Run Cmd/Freq Ref Source Sel Err].
• You can use these functions with the DI-A3 DI:
–H1-40 to H1-42 [Mbus 15C0h b0 Input Function to Mbus 15C0h b2 Input Function]
–H7-01 to H7-04 [Virtual In1 Select Function to Virtual In4 Select Function]
■ F3-01 D.In Funct Selection
No.
(Hex.)
Name Description
Default
(Range)
F3-01
(0390)
D.In Funct Selection
Sets the data format of digital input signals. Set o1-03 = 0 or 1 [FrqDisplay Unit Selection = 0.01
Hz or 0.01% (100%=E1-04)] to enable this function.
0
(0 - 8)
Note:
The input signal type is BCD when o1-03 = 2 or 3 [rpm or User-selected units]. The o1-03 value sets the setting units.
0 : BCD, 1% units
1 : BCD, 0.1% units
