Parameter List
11
11.11 o: KEYPAD
SIEPYEUOQ2A01G AC Drive Q2A Technical Manual 483
No.
(Hex.)
Name Description
Default
(Range)
Ref.
o2-03
(0507)
UserPar Set Default
Values
Sets the function to keep the settings of changed parameters as user parameter defaults
to use during initialization.
0 : No change
1 : Set defaults
2 : Clear all
0
(0 - 2)
833
o2-04
(0508)
Drive KVA Selection
Sets the Drive Model code. Set this parameter after replacing the control board.
Determined by the drive
(-)
834
o2-05
(0509)
LCD FreqRef
Mode@Home Screen
Sets the function that makes it necessary to push the button to change the
frequency reference value with the keypad when in Drive Mode.
0 : Disabled
1 : Enabled
0
(0, 1)
834
o2-06
(050A)
Keypad Disconnect
Detection
Sets the function that stops the drive if you disconnect the keypad connection cable
from the drive or if you damage the cable while the keypad is the Run command source.
0 : Disabled
1 : Enabled
Determined by o2-09
(0, 1)
835
o2-07
(0527)
Keypad Dir@Power-Up
Sets the direction of motor rotation when the drive is energized and the keypad is the
Run command source.
0 : Forward
1 : Reverse
0
(0, 1)
835
o2-09
(050D)
Region Code for
Initialization
- - -
o2-23
(11F8)
Ext24V Off Warning
Display
Sets the function to give a warning when the backup external 24 V power supply turns
off when the main circuit power supply is in operation.
0 : Disabled
1 : Enabled
0
(0, 1)
835
o2-26
(1563)
Ext24V Mode Warning
Display
When you connect a backup external 24 V power supply, this parameter sets the
function to trigger an alarm when the main circuit power supply voltage decreases.
Note:
The drive will not run when it is operating from one 24-V external power supply.
0 : Disabled
1 : Enabled
0
(0, 1)
836
o2-27
(1565)
BLE Disconn.
Selection@BLE Ctrl
Sets drive operation if the Bluetooth device is disconnected when you operate the drive
in Bluetooth Mode.
0 : Ramp->Stop
1 : Coast->Stop
2 : Fast Stop (C1-09)
3 : Alarm Only
4 : No Alarm Display
3
(0 - 4)
836
◆ o3: COPY FUNCTION
No.
(Hex.)
Name Description
Default
(Range)
Ref.
o3-01
(0515)
COPY Keypad Selection
of Mode
Sets the function that saves and copies drive parameters to a different drive with the
keypad.
0 : Copy Select
1 : Bck (Drive->OPE)
2 : Res (OPE->Drive)
3 : Verify (Check)
4 : Del (Clear OPE Memory)
0
(0 - 4)
836
o3-02
(0516)
COPY Allow Selection
Sets the copy function when o3-01 = 1 [COPY Keypad Selection of Mode = Bck
(Drive->OPE)].
0 : Disabled
1 : Enabled
0
(0, 1)
836
