12.10 o: KEYPAD
834 SIEPYEUOQ2A01G AC Drive Q2A Technical Manual
■ o2-04 Drive KVA Selection
No.
(Hex.)
Name Description
Default
(Range)
o2-04
(0508)
Drive KVA Selection
Sets the Drive Model code. Set this parameter after replacing the control board.
Determined by the drive
(-)
NOTICE: Set o2-04 [Drive KVA Selection] correctly. Failure to obey will decrease drive performance, cause the protection
function to operate incorrectly, and cause damage to the drive.
Note:
When the setting value of o2-04 changes, related parameter setting values also change. Refer to Defaults by Drive Model and Duty
Rating ND/HD on page 508 for more information.
These tables list the relation between o2-04 setting values and drive models.
o2-04 Setting Drive Model
62 2004
63 2006
65 2010
66 2012
67 2018
68 2021
6A 2030
6B 2042
6D 2056
6E 2070
6F 2082
70 2110
72 2138
73 2169
74 2211
75 2257
76 2313
77 2360
78 2415
92 4002
93 4004
94 4005
o2-04 Setting Drive Model
95 4007
96 4009
97 4012
99 4018
9A 4023
9C 4031
9D 4038
9E 4044
9F 4060
A1 4075
A2 4089
A3 4103
A4 4140
A5 4168
A6 4208
A7 4250
A8 4296
A9 4371
AA 4389
AC 4453
AD 4568
AE 4675
■ o2-05 LCD FreqRef Mode@Home Screen
No.
(Hex.)
Name Description
Default
(Range)
o2-05
(0509)
LCD FreqRef
Mode@Home Screen
Sets the function that makes it necessary to push the button to change the frequency
reference value with the keypad when in Drive Mode.
0
(0, 1)
0 : Disabled
You must push to use the keypad to change the frequency reference value.
1 : Enabled
The frequency reference changes when you enter it with the keypad. This then changes the output frequency. It is
not necessary to push . The drive keeps the frequency reference for 5 seconds after you use and on
the keypad to change the frequency reference value.
To Next Page
