Parameter Details
12
12.10 o: KEYPAD
SIEPYEUOQ2A01G AC Drive Q2A Technical Manual 835
■ o2-06 Keypad Disconnect Detection
No.
(Hex.)
Name Description
Default
(Range)
o2-06
(050A)
Keypad Disconnect
Detection
Sets the function that stops the drive if you disconnect the keypad connection cable from the drive
or if you damage the cable while the keypad is the Run command source.
Determined by o2-09
(0, 1)
This parameter continues to operate if the keypad installed to the drive becomes disconnected.
This parameter is enabled in these conditions:
• When b1-02 = 0 [Run Comm. Sel 1 = Keypad] or b1-16 = 0 [Run Comm. Sel 2 = Keypad]
• In LOCAL Mode
0 : Disabled
The drive continues operation when it detects a keypad disconnection.
1 : Enabled
The drive stops operation, detects oPr [Keypad Connection Fault], and the motor coasts to stop when the drive
detects a keypad disconnection.
■ o2-07 Keypad Dir@Power-Up
No.
(Hex.)
Name Description
Default
(Range)
o2-07
(0527)
Keypad Dir@Power-Up
Sets the direction of motor rotation when the drive is energized and the keypad is the Run
command source.
0
(0, 1)
This parameter is enabled in these conditions:
• When b1-02 = 0 [Run Comm. Sel 1 = Keypad] or b1-16 = 0 [Run Comm. Sel 2 = Keypad]
• In LOCAL Mode
0 : Forward
1 : Reverse
■ o2-09 Region Code for Initialization
No.
(Hex.)
Name Description
Default
(Range)
o2-09
(050D)
Region Code for
Initialization
- -
■ o2-23 Ext24V Off Warning Display
No.
(Hex.)
Name Description
Default
(Range)
o2-23
(11F8)
Ext24V Off Warning
Display
Sets the function to give a warning when the backup external 24 V power supply turns off when
the main circuit power supply is in operation.
0
(0, 1)
Note:
The drive will not run when it is operating from one 24-V external power supply.
0 : Disabled
The drive does not detect the loss of the 24-V external power supply.
1 : Enabled
The keypad shows the L24v [Ext. 24-V Power Supply Lost] indicator when the drive detects the loss of the 24-V
external power supply.
Note:
The minor fault signal is not output from H2-xx = 4 [Multi-Function Digital Out = Alarm].
To Next Page
