11.8 H: TERMINALS
462 SIEPYEUOQ2A01G AC Drive Q2A Technical Manual
No.
(Hex.)
Name Description
Default
(Range)
Ref.
H4-06
(0422)
RUN
AO2 An.Out Bias
Sets the bias of the monitor signal that is sent from MFAO terminal AO2.
Set the level of the analog signal sent from the AO2 terminal at 10 V or 20 mA as 100%
when an output for monitoring items is 0%.
0.0%
(-999.9 - +999.9%)
747
H4-07
(0423)
AO1 Signal Level Select
Sets the MFAO terminal AO1 output signal level.
Note:
Set jumper S5 on the terminal board to the correct position after changing this
parameter.
1 : 0 to 10 Vdc
2 : -10 to +10 Vdc
3 : 4 to 20 mA
1
(1 - 3)
747
H4-08
(0424)
AO2 Signal Level Select
Sets the MFAO terminal AO2 output signal level.
Note:
Set jumper S5 on the terminal board to the correct position after changing this
parameter.
1 : 0 to 10 Vdc
2 : -10 to +10 Vdc
3 : 4 to 20 mA
1
(1 - 3)
747
H4-20
(0B53)
An.Pwr Mon 100%
Level
Sets the level at 10 V when U1-08 [Output Power] is set for analog output.
0.00 kW
(0.00 - 650.00 kW)
747
◆ H5: MODBUS PORTS
No.
(Hex.)
Name Description
Default
(Range)
Ref.
H5-01
(0425)
Mbus Address
Sets the communication slave address for drives.
Note:
• Restart the drive after changing the parameter setting.
• Setting 0 will not let the drive respond to Modbus communications.
1FH
(0 - FFH)
747
H5-02
(0426)
Mbus BaudRate
Sets the communications speed for Modbus communications.
Note:
Restart the drive after you change the parameter setting.
1 : 1200 bps
2 : 2400 bps
3 : 4800 bps
4 : 9600 bps
5 : 19.2 kbps
6 : 38.4 kbps
7 : 57.6 kbps
8 : 76.8 kbps
9 : 115.2 kbps
4
(1 - 9)
748
H5-03
(0427)
Mbus Parity
Sets the communications parity used for Modbus communications.
Note:
Restart the drive after you change the parameter setting.
1 : Even parity
2 : Odd parity
3 : No parity
3
(1 - 3)
748
H5-04
(0428)
Mbus Error Stop
Sets the motor Stopping Method when the drive detects CE [Modbus Communication
Error] issues.
0 : Ramp->Stop
1 : Coast->Stop
2 : Fast Stop (C1-09)
3 : Alarm Only
3
(0 - 3)
748
H5-05
(0429)
Mbus Fault Detection
Selection
Sets the function that detects CE [Modbus Communication Error] issues during
Modbus communications.
0 : Disabled
1 : Enabled
1
(0, 1)
749
H5-06
(042A)
Mbus Tx Wait Time
Sets the time to wait to send a response message after the drive receives a command
message from the master.
Note:
Restart the drive after you change the parameter setting.
5 ms
(0 - 65 ms)
749
