10.8 Drive Exterior and Mounting Dimensions
402 SIEPYEUOQ2A01G AC Drive Q2A Technical Manual
■ 4371
Figure 10.17 Exterior and Mounting Dimensions Diagram 8
Table 10.49 400 V Class (UL Type 1)
Model
Dimensions mm (in.)
Weight
kg (lb.)
W H D D1 D2 W1 W2
W3
(max.)
H0 H1 H2 H3 H5 t1 t2 d
4371
444
(17.48)
1045
(41.14)
472
(18.58)
254
(10.00)
218
(8.58)
370
(14.57)
370
(14.57)
18
(0.709)
800
(31.50)
757
(29.80)
28
(1.102)
245
(9.65)
30
(1.181)
4.5
(0.177)
4.5
(0.177)
M12
119
(262.40)
◆ Knock-Out Hole Dimensions (UL Type 1)
■ 4002 to 4023
Figure 10.18 Knock-Out Dimensions Diagram 1 (Models: 4002 to 4023)
Model
Dimensions mm (in.)
D D1 D2 D3 W φd4
4002 to 4005
39
(1.54)
85
(3.35)
57.5
(2.26)
30
(1.18)
38.2
(1.50)
35
(1.38)
4007 to 4023
74
(2.91)
85
(3.35)
57.5
(2.26)
30
(1.18)
38.2
(1.50)
35
(1.38)
