11.7 F: OPTIONS
440 SIEPYEUOQ2A01G AC Drive Q2A Technical Manual
No.
(Hex.)
Name Description
Default
(Range)
Ref.
F3-13
(0BE6)
Expert
D3 Function Selection
Sets the function for terminal D3 of the DI-A3 when F3-01 = 8 [D.In Funct Selection =
MF Digital Input].
0
(0 - 4, 6 - 19F)
661
F3-14
(0BE7)
Expert
D4 Function Selection
Sets the function for terminal D4 of the DI-A3 when F3-01 = 8 [D.In Funct Selection =
MF Digital Input].
0
(0 - 4, 6 - 19F)
661
F3-15
(0BE8)
Expert
D5 Function Selection
Sets the function for terminal D5 of the DI-A3 when F3-01 = 8 [D.In Funct Selection =
MF Digital Input].
0
(0 - 4, 6 - 19F)
661
F3-16
(0BE9)
Expert
D6 Function Selection
Sets the function for terminal D6 of the DI-A3 when F3-01 = 8 [D.In Funct Selection =
MF Digital Input].
0
(0 - 4, 6 - 19F)
661
F3-17
(0BEA)
Expert
D7 Function Selection
Sets the function for terminal D7 of the DI-A3 when F3-01 = 8 [D.In Funct Selection =
MF Digital Input].
0
(0 - 4, 6 - 19F)
661
F3-18
(0BEB)
Expert
D8 Function Selection
Sets the function for terminal D8 of the DI-A3 when F3-01 = 8 [D.In Funct Selection =
MF Digital Input].
0
(0 - 4, 6 - 19F)
661
F3-19
(0BEC)
Expert
D9 Function Selection
Sets the function for terminal D9 of the DI-A3 when F3-01 = 8 [D.In Funct Selection =
MF Digital Input].
0
(0 - 4, 6 - 19F)
661
F3-20
(0BED)
Expert
DA Function Selection
Sets the function for terminal DA of the DI-A3 when F3-01 = 8 [D.In Funct Selection
= MF Digital Input]
0
(0 - 4, 6 - 19F)
662
F3-21
(0BEE)
Expert
DB Function Selection
Sets the function for terminal DB of the DI-A3 when F3-01 = 8 [D.In Funct Selection
= MF Digital Input].
0
(0 - 4, 6 - 19F)
662
F3-22
(0BEF)
Expert
DC Function Selection
Sets the function for terminal DC of the DI-A3 when F3-01 = 8 [D.In Funct Selection
= MF Digital Input].
0
(0 - 4, 6 - 19F)
662
F3-23
(0BF0)
Expert
DD Function Selection
Sets the function for terminal DD of the DI-A3 when F3-01 = 8 [D.In Funct Selection
= MF Digital Input].
0
(0 - 4, 6 - 19F)
662
F3-24
(0BF1)
Expert
DE Function Selection
Sets the function for terminal DE of the DI-A3 when F3-01 = 8 [D.In Funct Selection =
MF Digital Input].
0
(0 - 4, 6 - 19F)
662
F3-25
(0BF2)
Expert
DF Function Selection
Sets the function for terminal DF of the DI-A3 when F3-01 = 8 [D.In Funct Selection =
MF Digital Input].
0
(0 - 4, 6 - 19F)
662
◆ F4: ANALOG OUTPUT
No.
(Hex.)
Name Description
Default
(Range)
Ref.
F4-01
(0391)
Term.V1 Funct Selection
Sets the monitor signal output from terminal V1.
102
(000 - 999)
663
F4-02
(0392)
RUN
Term.V1 Gain
Sets the gain of the monitor signal that is sent from terminal V1. Sets the analog signal
output level from the terminal V1 at 10 Vor 20 mA as 100% when an output for
monitoring items is 100%.
100.0%
(-999.9 - +999.9%)
663
F4-03
(0393)
Term.V2 Function
Selection
Sets the number for monitor item of output from terminal V2.
103
(000 - 999)
663
F4-04
(0394)
RUN
Term.V2 Gain
Sets the gain of the monitor signal that is sent from terminal V2.
When an output for monitoring items is 0%, this parameter sets the analog signal output
level from the V2 terminal at 10 Vor 20 mA as 100%.
50.0%
(-999.9 - +999.9%)
664
F4-05
(0395)
RUN
Term.V1 Bias
Sets the bias of the monitor signal that is sent from terminal V1. Set the level of the
analog signal sent from the V1 terminal at 10 V or 20 mA as 100% when an output for
monitoring items is 0%.
0.0%
(-999.9 - +999.9%)
664
