10.5 Drive Derating
376 SIEPYEUOQ2A01G AC Drive Q2A Technical Manual
Model
Rated Current (A)
Heavy Duty Rating (HD1) Normal Duty Rating (ND1)
2 kHz 5 kHz 8 kHz 10 kHz 12.5 kHz 15 kHz 2 kHz 5 kHz 8 kHz 10 kHz 12.5 kHz 15 kHz
4038
31.0 31.0 31.0 27.5 23.0 18.6 38 36.3 31.0 27.5 23.0 18.6
4044
39.0 39.0 39.0 34.5 29.0 23.4 44 43.6 37.5 33.5 28.4 23.4
4060
45.0 45.0 45.0 39.1 31.8 24.4 60 53.7 44.9 39.1 31.7 24
4075
60.0 60.0 60.0 53.1 44.6 36.0 75 73.8 62.9 55.6 46.5 37
4089
75.0 75.0 75.0 66.4 55.7 45.0 89 88.8 75.8 67.2 56.4 46
4103
91.0 91.0 91.0 80.6 67.6 54.6 103 103.0 90.3 80.1 67.3 55
4140
112.0 112.0 91.8 78.4 - - 140 122.8 96.7 79 - -
4168
150.0 150.0 123.0 105.0 - - 168 150.5 124.4 107 - -
4208
180.0 180.0 147.6 126.0 - - 208 179.7 137.2 109 - -
4250
216.0 216.0 177.1 151.2 - - 250 221.8 179.4 151 - -
4296
260.0 260.0 213.2 182.0 - - 296 263.4 214.6 182 - -
4371
304.0 304.0 249.3 212.8 - - 371 327.2 261.6 218 - -
4389
371.0 371.0 304.2 259.7 - - 389 348 286.3 245 - -
4453
389.0 324.8 - - - - 453 349 - - - -
4568
453.0 378.3 - - - - 568 437 - - - -
4675
605.0 505.2 - - - - 675 529 - - - -
Table 10.15 Carrier Frequency and Rated Current Derating (≥ 460 V)
Model
Rated Current (A)
Heavy Duty Rating (HD2) Normal Duty Rating (ND2)
2 kHz 5 kHz 8 kHz 10 kHz 12.5 kHz 15 kHz 2 kHz 5 kHz 8 kHz 10 kHz 12.5 kHz 15 kHz
4002
2.1 1.9 1.6 1.4 1.1 0.9 2.1 2.0 1.8 1.7 1.5 1.4
4004
2.8 2.5 2.1 1.8 1.4 1.1 3.0 2.8 2.5 2.3 2.0 1.8
4005
4.3 3.9 3.4 3.0 2.6 2.2 4.8 4.6 4.3 4.0 3.8 3.5
4007
6.2 5.6 4.8 4.2 3.5 2.8 6.9 6.3 5.3 4.7 3.9 3.2
4009
8.6 7.9 6.9 6.2 5.4 4.6 7.6 7.0 6.1 5.5 4.8 4.1
4012
9.8 8.9 7.6 6.7 5.6 4.5 11.0 10.0 8.5 7.5 6.2 5.0
4018
14.1 12.9 11.0 9.7 8.2 6.6 15.2 13.9 11.8 10.5 8.8 7.1
4023
18.0 16.4 14.0 12.4 10.4 8.4 21 19.3 16.4 14.6 12.2 9.9
4031
27.2 24.7 21.0 18.5 15.4 12.4 27 24.5 20.9 18.4 15.4 12.3
4038
34.7 31.6 27.0 23.9 20.1 16.2 34 32.5 27.7 24.6 20.6 16.6
4044
34.0 34.0 34.0 30.1 25.3 20.4 40 39.6 34.1 30.5 25.9 21.3
4060
40.0 40.0 40.0 34.8 28.3 21.7 52 46.9 39.2 34.1 27.7 21
4075
52.0 52.0 52.0 46.1 38.6 31.2 65 64.1 54.6 48.3 40.4 33
4089
65.0 65.0 65.0 57.6 48.3 39.0 77 76.6 65.5 58.0 48.7 39
4103
77.0 77.0 77.0 68.2 57.2 46.2 96 96.0 84.1 74.6 62.8 51
4140
96.0 96.0 78.7 67.2 - - 124 108.7 85.7 70 - -
4168
124.0 124.0 101.7 86.8 - - 156 139.8 115.5 99 - -
4208
156.0 156.0 127.9 109.2 - - 180 155.5 118.7 94 - -
4250
180.0 180.0 147.6 126.0 - - 240 212.9 172.3 145 - -
4296
240.0 240.0 196.8 168.0 - - 302 268.8 218.9 186 - -
4371
302.0 302.0 247.6 211.4 - - 361 318.5 254.7 212 - -
4389
361.0 361.0 296.0 252.7 - - 414 370 303.3 259 - -
4453
414.0 345.0 - - - - 477 367 - - - -
