12.7 H: TERMINALS
746 SIEPYEUOQ2A01G AC Drive Q2A Technical Manual
Set the x-xx part of the U: MONITORS. For example, set H4-01 to 102 to monitor U1-02 [Output Frequency].
Note:
• The configurable monitor changes when the control method changes.
• To use in through mode, set this parameter to 000 or 031. You can set the terminal AO1 output level from the PLC through Modbus
communications or the communication option.
■ H4-02 AO1 An.Out Gain
No.
(Hex.)
Name Description
Default
(Range)
H4-02
(041E)
RUN
AO1 An.Out Gain
Sets the gain of the monitor signal that is sent from MFAO terminal AO1.
100.0%
(-999.9 - +999.9%)
The analog signal output from the AO1 terminal is a maximum of ±10 V (or 20 mA). Select the signal level with
H4-07 [AO1 Signal Level Select].
■ H4-03 AO1 An.Out Bias
No.
(Hex.)
Name Description
Default
(Range)
H4-03
(041F)
RUN
AO1 An.Out Bias
Sets the bias of the monitor signal that is sent from MFAO terminal AO1.
0.0%
(-999.9 - +999.9%)
The analog signal output from the AO1 terminal is a maximum of ±10 V (or 20 mA). Select the signal level with
H4-07 [AO1 Signal Level Select].
■ H4-04 AO2 An.Out Select
No.
(Hex.)
Name Description
Default
(Range)
H4-04
(0420)
AO2 An.Out Select
Sets the monitoring number to be output from the MFAO terminal AO2.
103
(000 - 999)
Set the x-xx part of the U: MONITORS. For example, set H4-04 to 102 to monitor U1-02 [Output Frequency].
Note:
• The configurable monitor changes when the control method changes.
• To use in through mode, set this parameter to 000 or 031. You can set the terminal AO2 output level from the PLC through Modbus
communications or the communication option.
■ H4-05 AO2 An.Out Gain
No.
(Hex.)
Name Description
Default
(Range)
H4-05
(0421)
RUN
AO2 An.Out Gain
Sets the gain of the monitor signal that is sent from MFAO terminal AO2.
50.0%
(-999.9 - +999.9%)
The analog signal output from the AO2 terminal is a maximum of ±10 V (or 20 mA). Select the signal level with
H4-08 [AO2 Signal Level Select].
Examples of possible settings:
When the output current of a monitoring item is 100% (drive rated current) in these examples, the voltage of AO2
terminal outputs at 5 V (50% of 10 V). Subsequently, the output current at the time the AO2 terminal outputs a
maximum voltage of 10 V will be 200% of the drive rated current.
• H4-04 = 103 [AO2 An.Out Select = Output Current]
• H4-05 = 50.0%
• H4-06 = 0.0% [AO2 An.Out Bias = 0.0%]
• H4-08 = 0 [0 to 10 V]
To Next Page
