11.20 Parameters Changed by PM Motor Code Selection
518 SIEPYEUOQ2A01G AC Drive Q2A Technical Manual
Parameter Unit Motor Code (setting value of E5-01)
PM Mot Resistance (Ohms/Phase) Ω 0.028 0.024 0.015 0.011
PM d-Axis Inductance (mH/Phase) mH 2.32 2.20 1.45 1.23
PM q-Axis Inductance (mH/Phase) mH 2.97 3.23 1.88 1.67
PM BackEMF Vpeak (mV/(rad/ s)) mVs/rad 639.3 708.0 640.7 677.0
PM BackEMF L-L Vrms (mV/rpm) mV/(r/min) 0.0 0.0 0.0 0.0
Max Output Frequency Hz 72.5 72.5 72.5 72.5
Max Output Voltage V 380.0 380.0 380.0 380.0
Base Frequency Hz 72.5 72.5 72.5 72.5
Min Output Frequency Hz 3.6 3.6 3.6 3.6
Motor Inertia kgm
2
0.56 0.83 0.96 1.61
Acc@Rated Torque
*1
s 0.171 0.213 0.201 0.281
Mot Inertia Acceleration Time s 0.171 0.213 0.201 0.281
Heavy Load Id Current % -15.8 -19.6 -14.9 -15.1
*1 Default settings vary depending on the setting of Drive KVA Selection.
Table 11.10 SSR1 Series Motor Code Setting for Specification of 400 V at 1150 min
-1
(r/min)
Parameter Unit Motor Code (setting value of E5-01)
E5-01 PM Mot Code Selection - 1432 1433 1435 1436 1438 143A 143B 143D
Voltage Class V 400 400 400 400 400 400 400 400
Capacity kW 0.4 0.75 1.5 2.2 3.7 5.5 7.5 11
Motor Rotation Speed min
-1
1150 1150 1150 1150 1150 1150 1150 1150
E5-02 PM Mot Rated Power (kW) kW 0.4 0.75 1.5 2.2 3.7 5.5 7.5 11.0
E5-03 PM Mot Rated Current
(FLA)
A 0.94 1.51 3.00 4.43 7.08 10.10 13.33 19.9
E5-04 PM Mot Pole Count - 6 6 6 6 6 6 6 6
E5-05 PM Mot Resistance (Ohms/
Phase)
Ω 19.320 10.800 4.456 2.044 1.483 1.215 0.660 0.443
E5-06 PM d-Axis Inductance (mH/
Phase)
mH 194.70 129.20 76.88 48.60 37.58 44.54 26.36 19.10
E5-07 PM q-Axis Inductance (mH/
Phase)
mH 252.84 160.90 97.52 61.40 47.65 56.26 34.20 24.67
E5-09 PM BackEMF Vpeak (mV/
(rad/ s))
mVs/rad 640.9 654.1 728.8 688.9 702.0 861.5 783.0 762.2
E5-24 PM BackEMF L-L Vrms
(mV/rpm)
mV/(r/
min)
0.0 0.0 0.0 0.0 0.0 0.0 0.0 0.0
E1-04 Max Output Frequency Hz 57.5 57.5 57.5 57.5 57.5 57.5 57.5 57.5
E1-05 Max Output Voltage V 380.0 380.0 380.0 380.0 380.0 380.0 380.0 380.0
E1-06 Base Frequency Hz 57.5 57.5 57.5 57.5 57.5 57.5 57.5 57.5
E1-09 Min Output Frequency Hz 2.9 2.9 2.9 2.9 2.9 2.9 2.9 2.9
C5-17 Motor Inertia kgm
2
0.0017 0.0023 0.0083 0.0136 0.0171 0.027 0.046 0.055
L3-24 Acc@Rated Torque
*1
s 0.062 0.044 0.080 0.090 0.067 0.072 0.088 0.073
n5-02 Mot Inertia Acceleration
Time
s 0.062 0.044 0.080 0.090 0.067 0.072 0.088 0.073
n8-49 Heavy Load Id Current % -8.8 -9.9 -9.3 -10.0 -12.8 -12.3 -15.3 -16.7
*1 Default settings vary depending on the setting of o2-04 [Drive KVA Selection].
Table 11.11 SSR1 Series Motor Code Setting for Specification of 400 V at 1150 min
-1
(r/min)
Parameter Unit Motor Code (setting value of E5-01)
E5-01 PM Mot Code Selection - 143E 143F 1440 1442 1443 1444
Voltage Class V 400 400 400 400 400 400
Capacity kW 15 18 22 30 37 45
