Q2 Q2A User Manual

Parameter List
11
11.20 Parameters Changed by PM Motor Code Selection
SIEPYEUOQ2A01G AC Drive Q2A Technical Manual 517
Parameter Unit Motor Code (setting value of E5-01)
PM q-Axis Inductance (mH/Phase) mH 166.96 113.19 80.59 60.32 40.45 30.94 33.45 19.63
PM BackEMF Vpeak (mV/(rad/ s)) mVs/rad 528.6 544.2 568.5 572.8 562.9 587.6 670.1 612.7
PM BackEMF L-L Vrms (mV/rpm)
mV/(r/
min)
0.0 0.0 0.0 0.0 0.0 0.0 0.0 0.0
Max Output Frequency Hz 72.5 72.5 72.5 72.5 72.5 72.5 72.5 72.5
Max Output Voltage V 380.0 380.0 380.0 380.0 380.0 380.0 380.0 380.0
Base Frequency Hz 72.5 72.5 72.5 72.5 72.5 72.5 72.5 72.5
Min Output Frequency Hz 3.6 3.6 3.6 3.6 3.6 3.6 3.6 3.6
Motor Inertia kgm
2
0.0017 0.0023 0.0043 0.0083 0.0136 0.017 0.027 0.046
Acc@Rated Torque
*1
s 0.098 0.071 0.066 0.087 0.085 0.072 0.084 0.096
Mot Inertia Acceleration Time s 0.098 0.071 0.066 0.087 0.085 0.072 0.084 0.096
Heavy Load Id Current % -6.6 -9.2 -13.5 -12.1 -13.7 -10.1 -12.2 -15.5
*1 Default settings vary depending on the setting of Drive KVA Selection.
Table 11.8 SSR1 Series Motor Code Setting for Specification of 400 V at 1450 min
-1
(r/min)
Parameter Unit Motor Code (setting value of E5-01)
PM Mot Code Selection - 133E 133F 1340 1342 1343 1344 1345
Voltage Class V 400 400 400 400 400 400 400
Capacity kW 15 18 22 30 37 45 55
Motor Rotation Speed min
-1
1450 1450 1450 1450 1450 1450 1450
PM Mot Rated Power (kW) kW 15 18.50 22.00 30.00 37.00 45.00 55.00
PM Mot Rated Current (FLA) A 27.4 32.9 37.6 52.5 63.2 76.4 96.1
PM Mot Pole Count - 6 6 6 6 6 6 6
PM Mot Resistance (Ohms/Phase) Ω 0.295 0.223 0.164 0.137 0.093 0.059 0.048
PM d-Axis Inductance (mH/Phase) mH 12.65 9.87 7.90 7.01 5.93 4.17 3.11
PM q-Axis Inductance (mH/Phase) mH 15.87 12.40 10.38 8.68 6.79 5.22 4.55
PM BackEMF Vpeak (mV/(rad/ s)) mVs/rad 624.6 610.4 655.4 708.4 739.2 703.0 747.1
PM BackEMF L-L Vrms (mV/rpm) mV/(r/min) 0.0 0.0 0.0 0.0 0.0 0.0 0.0
Max Output Frequency Hz 72.5 72.5 72.5 72.5 72.5 72.5 72.5
Max Output Voltage V 380.0 380.0 380.0 380.0 380.0 380.0 380.0
Base Frequency Hz 72.5 72.5 72.5 72.5 72.5 72.5 72.5
Min Output Frequency Hz 3.6 3.6 3.6 3.6 3.6 3.6 3.6
Motor Inertia kgm
2
0.055 0.064 0.116 0.140 0.259 0.312 0.42
Acc@Rated Torque
*1
s 0.085 0.080 0.122 0.108 0.161 0.160 0.175
Mot Inertia Acceleration Time s 0.085 0.080 0.122 0.108 0.161 0.160 0.175
Heavy Load Id Current % -15.1 -16.0 -15.7 -11.5 -6.8 -11.5 -14.8
*1 Default settings vary depending on the setting of Drive KVA Selection.
Table 11.9 SSR1 Series Motor Code Setting for Specification of 400 V at 1450 min
-1
(r/min)
Parameter Unit Motor Code (setting value of E5-01)
PM Mot Code Selection - 1346 1347 1348 1349
Voltage Class V 400 400 400 400
Capacity kW 75 90 110 132
Motor Rotation Speed min
-1
1450 1450 1450 1450
PM Mot Rated Power (kW) kW 75.00 90.00 110.00 132.00
PM Mot Rated Current (FLA) A 124.0 153.1 186.5 226.0
PM Mot Pole Count - 6 6 6 6
