12.6 F: OPTIONS
678 SIEPYEUOQ2A01G AC Drive Q2A Technical Manual
Note:
If F6-52 [DNet PCA Setting] and F6-53 [DNet PPA Setting] are not correct, the value is reset to default.
■ F6-54 DNet Idle Fault Detection
No.
(Hex.)
Name Description
Default
(Range)
F6-54
(03C5)
DNet Idle Fault Detection
Sets the function to detect EF0 [Option Card External Fault] when the drive does not receive
data from the DeviceNet master.
0
(0 - 4)
0 : Enabled
1 : Disabled, No Fault Detection
Does not detect EF0 issues.
2 : Vendor Specific
3 : RUN Forward
4 : RUN Reverse
■ F6-55 DNet Baud Monitor
No.
(Hex.)
Name Description
Default
(Range)
F6-55
(03C6)
DNet Baud Monitor
Sets the function to see the actual DeviceNet communications speed using the keypad. This
parameter functions as a monitor only.
0
(0 - 2)
0 : 125 kbps
1 : 250 kbps
2 : 500 kbps
■ F6-56 DNet Speed Scale Factor
No.
(Hex.)
Name Description
Default
(Range)
F6-56
(03D7)
DNet Speed Scale Factor
Sets the speed scale for DeviceNet communication.
0
(-15 - +15)
■ F6-57 DNet Current Scale Factor
No.
(Hex.)
Name Description
Default
(Range)
F6-57
(03D8)
DNet Current Scale Factor
Sets the current scale of the DeviceNet communication master.
0
(-15 - +15)
■ F6-58 DNet Torque Scale Factor
No.
(Hex.)
Name Description
Default
(Range)
F6-58
(03D9)
DNet Torque Scale Factor
Sets the torque scale of the DeviceNet communication master.
0
(-15 - +15)
■ F6-59 DNet Power Scaling
No.
(Hex.)
Name Description
Default
(Range)
F6-59
(03DA)
DNet Power Scaling
Sets the power scale of the DeviceNet communication master.
0
(-15 - +15)
■ F6-60 DNet Voltage Scale
No.
(Hex.)
Name Description
Default
(Range)
F6-60
(03DB)
DNet Voltage Scale
Sets the voltage scale of the DeviceNet communication master.
0
(-15 - +15)
