11.7 F: OPTIONS
446 SIEPYEUOQ2A01G AC Drive Q2A Technical Manual
No.
(Hex.)
Name Description
Default
(Range)
Ref.
F7-09
(03ED)
Gateway Addr 1
Sets the first octet of the gateway address of the connected network.
Note:
Set this parameter when F7-13 = 0 [Addr Mode@Startup = Static].
192
(0 - 255)
681
F7-10
(03EE)
Gateway Addr 2
Sets the second octet of the gateway address of the connected network.
Note:
Set this parameter when F7-13 = 0 [Addr Mode@Startup = Static].
168
(0 - 255)
681
F7-11
(03EF)
Gateway Addr 3
Sets the third octet of the gateway address of the connected network.
Note:
Set this parameter when F7-13 = 0 [Addr Mode@Startup = Static].
1
(0 - 255)
681
F7-12
(03F0)
Gateway Addr 4
Sets the fourth octet of the gateway address of the connected network.
Note:
Set this parameter when F7-13 = 0 [Addr Mode@Startup = Static].
1
(0 - 255)
681
F7-13
(03F1)
Addr Mode@Startup
Sets the method to set option card IP addresses.
0 : Static
1 : BOOTP
2 : DHCP
Note:
• The following setting values are available when using the PROFINET
communication option card (SI-EP3).
–0: Static
–2: DCP
• When F7-13 = 0, set parameters F7-01 to F7-12 [Subnet Mask 3 to Gateway Addr
4] to set the IPAddress. Be sure to set a different IP address for each drive on the
network.
2
(0 - 2)
681
F7-14
(03F2)
Duplex Mode Selection
Sets the duplex mode setting method.
0 : Half/Half
1 : Auto/Auto
2 : Full/Full
3 : Half/Auto
4 : Half/Full
5 : Auto/Half
6 : Auto/Full
7 : Full/Half
8 : Full/Auto
1
(0 - 8)
681
F7-15
(03F3)
Comm. BaudRate
Sets the communications speed.
10 : 10/10 Mbps
102 : 100/10 Mbps
10
(10, 102)
682
F7-16
(03F4)
Timeout Value
Sets the detection time for a communications timeout.
Note:
Set this parameter to 0.0 to disable the connection timeout function.
0.0 s
(0.0 - 30.0 s)
682
F7-17
(03F5)
E/IP Speed Scale Factor
Sets the scaling factor for the speed monitor in the EtherNet/IP Class ID 2AH Object.
0
(-15 - +15)
682
F7-18
(03F6)
E/IP Current Scale
Factor
Sets the scaling factor for the output current monitor in the EtherNet/IP Class ID 2AH
Object.
0
(-15 - +15)
682
F7-19
(03F7)
E/IP Torque Scale Factor
Sets the scaling factor for the torque monitor in the EtherNet/IP Class ID 2AH Object.
0
(-15 - +15)
682
F7-20
(03F8)
E/IP Power Scale Factor
Sets the scaling factor for the power monitor in the EtherNet/IP Class ID 2AH Object.
0
(-15 - +15)
683
F7-21
(03F9)
E/IP Voltage Scale
Factor
Sets the scaling factor for the voltage monitor in the EtherNet/IP Class ID 2AH Object.
0
(-15 - +15)
683
F7-22
(03FA)
E/IP Time Scale Factor
Sets the scaling factor for the time monitor in the EtherNet/IP Class ID 2AH Object.
0
(-15 - +15)
683
F7-23 to F7-27
(03FB - 03FF)
F7-28 to F7-32
(0370 - 0374)
DynOut.Ass116 P1 to 5
for CommCard
DynOut.Ass116 P6 to 10
for CommCard
Sets Output Assembly 116. The drive writes the values from Output Assembly 116 to
the Modbus address register that is stored for each parameter. The drive will not write
the values from Output Assembly 116 to the registers when the Modbus address is 0.
0 683
