Parameter Details
12
12.6 F: OPTIONS
SIEPYEUOQ2A01G AC Drive Q2A Technical Manual 681
Note:
Set this parameter when F7-13 = 0 [Addr Mode@Startup = Static].
■ F7-09 Gateway Addr 1
No.
(Hex.)
Name Description
Default
(Range)
F7-09
(03ED)
Gateway Addr 1
Sets the first octet of the gateway address of the connected network.
192
(0 - 255)
Note:
Set this parameter when F7-13 = 0 [Addr Mode@Startup = Static].
■ F7-10 Gateway Addr 2
No.
(Hex.)
Name Description
Default
(Range)
F7-10
(03EE)
Gateway Addr 2
Sets the second octet of the gateway address of the connected network.
168
(0 - 255)
Note:
Set this parameter when F7-13 = 0 [Addr Mode@Startup = Static].
■ F7-11 Gateway Addr 3
No.
(Hex.)
Name Description
Default
(Range)
F7-11
(03EF)
Gateway Addr 3
Sets the third octet of the gateway address of the connected network.
1
(0 - 255)
Note:
Set this parameter when F7-13 = 0 [Addr Mode@Startup = Static].
■ F7-12 Gateway Addr 4
No.
(Hex.)
Name Description
Default
(Range)
F7-12
(03F0)
Gateway Addr 4
Sets the fourth octet of the gateway address of the connected network.
1
(0 - 255)
Note:
Set this parameter when F7-13 = 0 [Addr Mode@Startup = Static].
■ F7-13 Addr Mode@Startup
No.
(Hex.)
Name Description
Default
(Range)
F7-13
(03F1)
Addr Mode@Startup
Sets the method to set option card IP addresses.
2
(0 - 2)
0 : Static
1 : BOOTP
2 : DHCP
Note:
• The following setting values are available when using the PROFINET communication option card (SI-EP3).
–0: Static
–2: DHCP
• When F7-13 = 0, set parameters F7-01 to F7-12 [IP Address 1 to Gateway Addr 4] to set the IP Address. Be sure to set a different IP
address for each drive on the network.
■ F7-14 Duplex Mode Selection
No.
(Hex.)
Name Description
Default
(Range)
F7-14
(03F2)
Duplex Mode Selection
Sets the duplex mode setting method.
1
(0 - 8)
0 : Half/Half
