12.6 F: OPTIONS
682 SIEPYEUOQ2A01G AC Drive Q2A Technical Manual
1 : Auto/Auto
2 : Full/Full
3 : Half/Auto
Port 1 is set to “Half” and port 2 is set to “Auto”.
4 : Half/Full
Port 1 is set to “Half” and port 2 is set to “Full”.
5 : Auto/Half
Port 1 is set to “Auto” and port 2 is set to “Half”.
6 : Auto/Full
Port 1 is set to “Auto” and port 2 is set to “Full”.
7 : Full/Half
Port 1 is set to “Full” and port 2 is set to “Half”.
8 : Full/Auto
Port 1 is set to “Full” and port 2 is set to “Auto”.
■ F7-15 Comm. BaudRate
No.
(Hex.)
Name Description
Default
(Range)
F7-15
(03F3)
Comm. BaudRate
Sets the communications speed.
10
(10, 102)
10 : 10/10 Mbps
102 : 100/10 Mbps
Note:
Set this parameter when F7-14 = 0 or 2 [Duplex Mode Selection = Half/Half or Full/Full].
■ F7-16 Timeout Value
No.
(Hex.)
Name Description
Default
(Range)
F7-16
(03F4)
Timeout Value
Sets the detection time for a communications timeout.
0.0 s
(0.0 - 30.0 s)
Note:
Set this parameter to 0.0 to disable the connection timeout function.
■ F7-17 E/IP Speed Scale Factor
No.
(Hex.)
Name Description
Default
(Range)
F7-17
(03F5)
E/IP Speed Scale Factor
Sets the scaling factor for the speed monitor in the EtherNet/IP Class ID 2AH Object.
0
(-15 - +15)
■ F7-18 E/IP Current Scale Factor
No.
(Hex.)
Name Description
Default
(Range)
F7-18
(03F6)
E/IP Current Scale Factor
Sets the scaling factor for the output current monitor in the EtherNet/IP Class ID 2AH Object.
0
(-15 - +15)
■ F7-19 E/IP Torque Scale Factor
No.
(Hex.)
Name Description
Default
(Range)
F7-19
(03F7)
E/IP Torque Scale Factor
Sets the scaling factor for the torque monitor in the EtherNet/IP Class ID 2AH Object.
0
(-15 - +15)
