Parameter Details
12
12.6 F: OPTIONS
SIEPYEUOQ2A01G AC Drive Q2A Technical Manual 683
■ F7-20 E/IP Power Scale Factor
No.
(Hex.)
Name Description
Default
(Range)
F7-20
(03F8)
E/IP Power Scale Factor
Sets the scaling factor for the power monitor in the EtherNet/IP Class ID 2AH Object.
0
(-15 - +15)
■ F7-21 E/IP Voltage Scale Factor
No.
(Hex.)
Name Description
Default
(Range)
F7-21
(03F9)
E/IP Voltage Scale Factor
Sets the scaling factor for the voltage monitor in the EtherNet/IP Class ID 2AH Object.
0
(-15 - +15)
■ F7-22 E/IP Time Scale Factor
No.
(Hex.)
Name Description
Default
(Range)
F7-22
(03FA)
E/IP Time Scale Factor
Sets the scaling factor for the time monitor in the EtherNet/IP Class ID 2AH Object.
0
(-15 - +15)
■ F7-23 to F7-32 DynOut.Ass116 P1 to 5 for CommCard and DynOut.Ass116 P6 to 10 for
CommCard
No.
(Hex.)
Name Description
Default
(Range)
F7-23 to F7-27
(03FB - 03FF)
F7-28 to F7-32
(0370 - 0374)
DynOut.Ass116 P1 to 5 for
CommCard
DynOut.Ass116 P6 to 10
for CommCard
Sets Output Assembly 116. The drive writes the values from Output Assembly 116 to the Modbus
address register that is stored for each parameter. The drive will not write the values from Output
Assembly 116 to the registers when the Modbus address is 0.
0
■ F7-33 to F7-42 DynIn.Ass166 P1 to 10 for CommCard
No.
(Hex.)
Name Description
Default
(Range)
F7-33 to F7-42
(0375 - 037E)
DynIn.Ass166 P1 to 10 for
CommCard
Sets Input Assembly 166. The drive sends the values from the Modbus address registers stored for
each parameter to Input Assembly 166. The drive returns the default register value for the option
card when the Modbus address is 0 and the value sent to Input Assembly 166 is not defined.
0
■ F7-60 PZD1 WR(CtrlWrd)
No.
(Hex.)
Name Description
Default
(Range)
F7-60
(0780)
PZD1 WR(CtrlWrd)
Sets the Modbus address for PZD1 (PPO output). PZD1 (PPO output) functions as the STW when
F7-60 = 0, 1, or 2.
0
■ F7-61 PZD2 WR(FRef)
No.
(Hex.)
Name Description
Default
(Range)
F7-61
(0781)
PZD2 WR(FRef)
Sets the Modbus address for PZD2 (PPO output). PZD2 (PPO output) functions as the HSW when
F7-61 = 0, 1, or 2.
0
■ F7-62 PZD3 Write
No.
(Hex.)
Name Description
Default
(Range)
F7-62
(0782)
PZD3 Write
Sets the Modbus address for PZD3 (PPO output). A value of 0, 1, or 2 will disable the PZD3
(PPO output) write operation to the Modbus register.
0
