Parameter List
11
11.7 F: OPTIONS
SIEPYEUOQ2A01G AC Drive Q2A Technical Manual 447
No.
(Hex.)
Name Description
Default
(Range)
Ref.
F7-33 to F7-42
(0375 - 037E)
DynIn.Ass166 P1 to 10
for CommCard
Sets Input Assembly 166. The drive sends the values from the Modbus address registers
stored for each parameter to Input Assembly 166. The drive returns the default register
value for the option card when the Modbus address is 0 and the value sent to Input
Assembly 166 is not defined.
0 683
F7-60
(0780)
PZD1 WR(CtrlWrd)
Sets the Modbus address for PZD1 (PPO output). PZD1 (PPO output) functions as the
STW when F7-60 = 0, 1, or 2.
0 683
F7-61
(0781)
PZD2 WR(FRef)
Sets the Modbus address for PZD2 (PPO output). PZD2 (PPO output) functions as the
HSW when F7-61 = 0, 1, or 2.
0 683
F7-62
(0782)
PZD3 Write
Sets the Modbus address for PZD3 (PPO output). A value of 0, 1, or 2 will disable the
PZD3 (PPO output) write operation to the Modbus register.
0 683
F7-63
(0783)
PZD4 Write
Sets the Modbus address for PZD4 (PPO output). A value of 0, 1, or 2 will disable the
PZD4 (PPO output) write operation to the Modbus register.
0 684
F7-64
(0784)
PZD5 Write
Sets the Modbus address for PZD5 (PPO output). A value of 0, 1, or 2 will disable the
PZD5 (PPO output) write operation to the Modbus register.
0 684
F7-65
(0785)
PZD6 Write
Sets the Modbus address for PZD6 (PPO output). A value of 0, 1, or 2 will disable the
PZD6 (PPO output) write operation to the Modbus register.
0 684
F7-66
(0786)
PZD7 Write
Sets the Modbus address for PZD7 (PPO output). A value of 0, 1, or 2 will disable the
PZD7 (PPO output) write operation to the Modbus register.
0 684
F7-67
(0787)
PZD8 Write
Sets the Modbus address for PZD8 (PPO output). A value of 0, 1, or 2 will disable the
PZD8 (PPO output) write operation to the Modbus register.
0 684
F7-68
(0788)
PZD9 Write
Sets the Modbus address for PZD9 (PPO output). A value of 0, 1, or 2 will disable the
PZD9 (PPO output) write operation to the Modbus register.
0 684
F7-69
(0789)
PZD10 Write
Sets the Modbus address for PZD10 (PPO output). A value of 0, 1, or 2 will disable the
PZD10 (PPO output) write operation to the Modbus register.
0 684
F7-70
(078A)
PZD1 RD (StatWord)
Sets the Modbus address for PZD1 (PPO Read). PZD1 (PPO input) functions as the
ZSW when F7-70 = 0.
0 684
F7-71
(078B)
PZD2 RD (OutFreq)
Sets the Modbus address for PZD2 (PPO Read). PZD2 (PPO input) functions as the
HIW when F7-71 = 0.
0 685
F7-72
(078C)
PZD3 Read
Sets the Modbus address for PZD3 (PPO Read). A value of 0 will disable the PZD3
(PPO input) load operation from the Modbus register.
0 685
F7-73
(078D)
PZD4 Read
Sets the Modbus address for PZD4 (PPO Read). A value of 0 will disable the PZD4
(PPO input) load operation from the Modbus register.
0 685
F7-74
(078E)
PZD5 Read
Sets the Modbus address for PZD5 (PPO Read). A value of 0 will disable the PZD5
(PPO input) load operation from the Modbus register.
0 685
F7-75
(078F)
PZD6 Read
Sets the Modbus address for PZD6 (PPO Read). A value of 0 will disable the PZD6
(PPO input) load operation from the Modbus register.
0 685
F7-76
(0790)
PZD7 Read
Sets the Modbus address for PZD7 (PPO Read). A value of 0 will disable the PZD7
(PPO input) load operation from the Modbus register.
0 685
F7-77
(0791)
PZD8 Read
Sets the Modbus address for PZD8 (PPO Read). A value of 0 will disable the PZD8
(PPO input) load operation from the Modbus register.
0 685
F7-78
(0792)
PZD9 Read
Sets the Modbus address for PZD9 (PPO Read). A value of 0 will disable the PZD9
(PPO input) load operation from the Modbus register.
0 685
F7-79
(0793)
PZD10 Read
Sets the Modbus address for PZD10 (PPO Read). A value of 0 will disable the PZD10
(PPO input) load operation from the Modbus register.
0 686
