12.5 E: MOTOR
640 SIEPYEUOQ2A01G AC Drive Q2A Technical Manual
0 : V/f Control
1 : PG V/f Control
2 : OLVector
3 : CLVector
■ E3-04 M2 Max Out Frequency
No.
(Hex.)
Name Description
Default
(Range)
E3-04
(031A)
M2 Max Out Frequency
Set the maximum output frequency for the motor 2 V/f pattern.
Determined by E3-01
(40.0 - 590.0 Hz)
■ E3-05 M2 Max Out Voltage
No.
(Hex.)
Name Description
Default
(Range)
E3-05
(031B)
M2 Max Out Voltage
Sets the maximum output voltage for the motor 2 V/f pattern.
Determined by E3-01
(400 V Class: 0.0 - 510.0
V)
■ E3-06 M2 Base Frequency
No.
(Hex.)
Name Description
Default
(Range)
E3-06
(031C)
M2 Base Frequency
Sets the base frequency for the motor 2 V/f pattern.
Determined by E3-01
(0.0 - E3-04)
■ E3-07 M2 Mid A Frequency
No.
(Hex.)
Name Description
Default
(Range)
E3-07
(031D)
M2 Mid A Frequency
Sets a middle output frequency for the motor 2 V/f pattern.
Determined by E3-01
(0.0 - E3-04)
■ E3-08 M2 Mid A Voltage
No.
(Hex.)
Name Description
Default
(Range)
E3-08
(031E)
M2 Mid AVoltage
Sets a middle output voltage for the motor 2 V/f pattern.
Determined by E3-01
(400 V Class: 0.0 - 510.0
V)
■ E3-09 M2 Min Out Frequency
No.
(Hex.)
Name Description
Default
(Range)
E3-09
(031F)
M2 Min Out Frequency
Sets the minimum output frequency for the motor 2 V/f pattern.
Determined by E3-01
(0.0 - E3-04)
■ E3-10 M2 Min Out Voltage
No.
(Hex.)
Name Description
Default
(Range)
E3-10
(0320)
M2 Min Out Voltage
Sets the minimum output voltage for the motor 2 V/f pattern.
Determined by E3-01
(400 V Class: 0.0 - 510.0
V)
■ E3-11 M2 Mid B Frequency
No.
(Hex.)
Name Description
Default
(Range)
E3-11
(0345)
Expert
M2 Mid B Frequency
Sets a middle output frequency for the motor 2 V/f pattern. Set this parameter to adjust the V/f
pattern for the constant output range. Usually it is not necessary to change this setting.
0.0 Hz
(0.0 - E3-04)
