Q2 Q2A - Page 208

5.3 UL Standards
208 SIEPYEUOQ2A01G AC Drive Q2A Technical Manual
Model Terminals
Recommended
Gauge
AWG, kcmil
Applicable Gauge
(IP20 Applicable
Gauge
*1
)
AWG, kcmil
Wire
Stripping
Length
*2
mm
Terminal Screw
Tightening Torque
N∙m (lb∙in.)
Size Shape
4075
R/L1, S/L2, T/L3 3
14 - 3
(12 - 3)
18 M5 Slotted (-)
2.3 - 2.5
(19.8 - 22)
*3
U/T1, V/T2, W/T3 3
14 - 3
(12 - 3)
18 M5 Slotted (-)
2.3 - 2.5
(19.8 - 22)
*3
-, +1 2
14 - 2
(10 - 2)
18 M5 Slotted (-)
2.3 - 2.5
(19.8 - 22)
*3
B1, B2 6
14 - 6
(14 - 6)
10 M4 Slotted (-)
1.5 - 1.7
(13.5 - 15)
6
6 - 4
(-)
- M6 Hex bolt (+)
5.4 - 6.0
(47.8 - 53.1)
4089
R/L1, S/L2, T/L3 2
14 - 2
(10 - 2)
18 M5 Slotted (-)
2.3 - 2.5
(19.8 - 22)
*3
U/T1, V/T2, W/T3 2
14 - 2
(10 - 2)
18 M5 Slotted (-)
2.3 - 2.5
(19.8 - 22)
*3
-, +1 1/0
14 - 1/0
(6 - 1/0)
20 M6
Hex socket cap
(WAF: 5 mm)
5 - 5.5
(45 - 49)
B1, B2 6
14 - 6
(14 - 6)
18 M5 Slotted (-)
2.3 - 2.5
(19.8 - 22)
*3
4
6 - 4
(-)
- M6 Hex bolt (+)
5.4 - 6.0
(47.8 - 53.1)
4103
R/L1, S/L2, T/L3 1/0
6 - 2/0
(2 - 2/0)
27 M6
Hex socket cap
(WAF: 5 mm)
8 - 9
(71 - 80)
U/T1, V/T2, W/T3 1
6 - 2/0
(2 - 2/0)
27 M6
Hex socket cap
(WAF: 5 mm)
8 - 9
(71 - 80)
-, +1 2/0
2 - 4/0
(2 - 4/0)
27 M8
Hex socket cap
(WAF: 6 mm)
10 - 12
(89 - 107)
B1, B2 3
14 - 3
(10 - 3)
21 M6 Minus (-)
3 - 3.5
(27 - 31)
4
6 - 4
(-)
- M6 Hex bolt (+)
5.4 - 6.0
(47.8 - 53.1)
4140
R/L1, S/L2, T/L3 3/0
2 - 250
(2/0 - 250)
37 M10
Hex socket cap
(WAF: 8 mm)
12 - 14
(107 - 124)
U/T1, V/T2, W/T3 2/0
2 - 300
(3/0 - 300)
37 M10
Hex socket cap
(WAF: 8 mm)
12 - 14
(107 - 124)
-, -, +1, +1
*4
2
6 - 2/0
(1/0 - 2/0)
28 M6
Hex socket cap
(WAF: 5 mm)
8 - 9
(71 - 80)
B1, B2
*5
1
4 - 2/0
(1 - 2/0)
28 M8
Hex socket cap
(WAF: 6 mm)
8 - 9
(71 - 80)
4
4 - 1/0
(-)
- M8 Hex bolt (slotted)
9.0 - 11
(79.7 - 97.4)
4168
R/L1, S/L2, T/L3 4/0
2 - 250
(2/0 - 250)
37 M10
Hex socket cap
(WAF: 8 mm)
12 - 14
(107 - 124)
U/T1, V/T2, W/T3 4/0
2 - 300
(3/0 - 300)
37 M10
Hex socket cap
(WAF: 8 mm)
12 - 14
(107 - 124)
-, -, +1, +1
*4
1/0
6 - 2/0
(1/0 - 2/0)
28 M6
Hex socket cap
(WAF: 5 mm)
8 - 9
(71 - 80)
B1, B2
*5
1/0
4 - 2/0
(1 - 2/0)
28 M8
Hex socket cap
(WAF: 6 mm)
8 - 9
(71 - 80)
4
4 - 1/0
(-)
- M8 Hex bolt (slotted)
9.0 - 11
(79.7 - 97.4)
