Q2 Q2A User Manual

Receiving
1
1.1 Model Number and Nameplate Check
SIEPYEUOQ2A01G AC Drive Q2A Technical Manual 21
Table 1.1 Model Number Details
No. Description
1 Q2 Series
2 A Series
3 IP Protection Class
• A: IP20
4 Input Power Supply Voltage
• 2: Three-Phase AC 200 V Class
• 4: Three-Phase AC 400 V Class
5 Rated Output Current
Note:
Refer to the rated output current list for more information.
6
Specification
• A: Standard
7 Coating Specification
• A: Standard
8 Version
■ Rated Output Current
These output current values are applicable for drives that operate at standard specifications.
• These output current values are applicable for drives that operate at standard specifications.
• Derate the current in applications that:
– Increase the carrier frequency
– Have high ambient temperature
– Install drives side-by-side.
• Use C6-01 [ND/HD Duty Selection] to select Normal Duty rating (ND) or Heavy Duty rating (HD).
Table 1.2 Three-Phase AC 200 V Class
Model
Heavy Duty Rating (HD)
[C6-01 = 0]
(Default)
Normal Duty Rating (ND)
[C6-01 = 1]
Maximum Applicable Motor
Output
kW
Rated Output Current
A
Maximum Applicable Motor
Output
kW
Rated Output Current
A
2004 0.55 3.2 0.75 3.5
2006 0.75 5 1.1 6
2010 1.5 8 2.2 9.6
2012 2.2 11 3 12.2
2018 3 14 4 17.5
2021 4 17.5 5.5 21
2030 5.5 25 7.5 30
2042 7.5 33 11 42
2056 11 47 15 56
2070 15 60 18.5 70
2082 18.5 75 22 82
2110 22 88 30 110
2138 30 115 37 138
2169 37 145 45 169
2211 45 180 55 211
2257 55 215 75 257
2313 75 283 90 313
2360 90 346 110 360
2415 110 415 - -
