Standards Compliance
5
5.3 UL Standards
SIEPYEUOQ2A01G AC Drive Q2A Technical Manual 211
Model
Recommended Gauge (AWG, kcmil)
Terminal
Screw Size
Crimp
Terminal
Model
Crimping Tool
Insulation
Cap Model
R/L1
S/L2
T/L3
U/T1
V/T2
W/T3
-, +1 +3 Tool Model Die Jaw
2070 - 2110 - - - - 6 M6 R14-6 YA-4 AD-902 TP-014
2138 - - - - 4 M6 R22-6 YA-5 AD-953 TP-022
2169, 2211 - - - - 4 M8 R22-8 YA-5 AD-953 TP-022
2257
- - - - 3
M10
R38-10
YF-1
YET-150-1
TD-224, TD-
212
TP-038
- - - 1/0 × 2P - R60-10
TD-225, TD-
213
TP-060
2/0 × 2P 2/0 × 2P - - - 80-10
TD-227, TD-
214
TP-080
- - 4/0 × 2P - - R100-10
TD-228, TD-
214
TP-100
2313
- - - - 2
M10
R38-10
YF-1
YET-150-1
TD-224, TD-
212
TP-038
- - - 1/0 × 2P - R60-10
TD-225, TD-
213
TP-060
- 3/0 × 2P - - - 80-10
TD-227, TD-
214
TP-080
4/0 × 2P - - - - R100-10
TD-228, TD-
214
TP-100
- - 250 × 2P - - R150-10
TD-229, TD-
215
TP-150
2360
- - - - 1
M12
R60-12
YF-1
YET-300-1
TD-321, TD-
311
TP-060
- - - 3/0 × 2P - 80-12
TD-323, TD-
312
TP-080
250 × 2P 250 × 2P - - - R150-12
TD-325, TD-
313
TP-150
- - 350 × 2P - - R200-12
TD-327, TD-
314
TP-200
2415
- - - - 1
M12
R60-12
YF-1
YET-300-1
TD-321, TD-
311
TP-060
- - - 3/0 × 2P - 80-12
TD-323, TD-
312
TP-080
250 × 2P -
- - - R150-12
TD-325, TD-
313
TP-150
- 300 × 2P
- - 350 × 2P - - R200-12
TD-327, TD-
314
TP-200
Table 5.12 Closed-Loop Crimp Terminals and Insulation Caps for 400 V Class
Model
Recommended Gauge (AWG, kcmil)
Terminal
Screw Size
Crimp
Terminal
Model
Crimping Tool
Insulation
Cap Model
R/L1
S/L2
T/L3
U/T1
V/T2
W/T3
-, +1 +3 Tool Model Die Jaw
4002, 4004 - - - - 12 M4 R5.5-4 YA-4 AD-900 TP-005
4005 - 4012 - - - - 10 M4 R5.5-4 YA-4 AD-900 TP-005
4018, 4023 - - - - 10 M5 R5.5-5 YA-4 AD-900 TP-005
4031 - - - - 8 M6 R8-6 YA-4 AD-901 TP-008
4038 - - - - 6 M6 R14-6 YA-4 AD-902 TP-014
4044, 4060 - - - - 6 M6 R14-6 YA-4 AD-902 TP-014
4075 - - - - 6 M6 R14-6 YA-4 AD-902 TP-014
4089, 4103 - - - - 4 M6 R22-6 YA-5 AD-953 TP-022
4140, 4168 - - - - 4 M8 R22-8 YA-5 AD-953 TP-022
