Q2 Q2A User Manual

6.2 Modbus Communications
248 SIEPYEUOQ2A01G AC Drive Q2A Technical Manual
Regis
ter No.
(Hex.)
Description
0039 PID Input: Signed, ±100%/±maximum output frequency (Units:0.1%)
003A PID Output: Signed, ±100%/±maximum output frequency (Units:0.1%)
003B -
003C
Reserved
003D
Communications error description
Note:
The drive saves the description of the communications error until you
reset the fault.
bit 0
CRC Error
bit 1 Data Length Error
bit 2 Reserved
bit 3 Parity Error
bit 4 Overrun Error
bit 5 Framing Error
bit 6 Timeout
bit 7 - F Reserved
003E
Output
frequency
Units: min
-1
or r/min
Note:
Set Motor Pole Count E2-04, E4-04, E5-04, E9-08.
003F
0.01 % units
0040 -
004A
Used with U1: STATUS. Refer to the U: MONITORS for parameter details.
004B
U1-12 [Drive Status]
bit 0 1: During run
bit 1 1: During zero speed
bit 2 1: During reverse
bit 3 1: During reset signal input
bit 4 1: During speed agreement
bit 5 1: Drive operation ready
bit 6 1: Minor Fault
bit 7 1: Fault
bit 8 1: oPExx [Operation Error] generation
bit 9 1: Recovery from momentary power loss, 0: Power recovery
bit A 1: Motor 2 Selection
bit B Reserved
bit E ComRef status/ NetRef status
bit F ComCtrl status/ NetCtrl status
004C -
007E
Use with U1: STATUS, U4: MAINTENANCE, U5: PID, U6: ADVANCED.
Refer to U2: FAULT and U3: FAULT HISTORY for details.
007F
Minor fault code (Refer to “Minor fault description” for more information on
the minor fault codes.)
0080 -
0097
Use with U2: FAULT, U3: FAULT HISTORY. Refer to U: MONITORS for
details, and refer to “Fault Trace/Fault History Descriptions” for details on
register values.
0098 -
0099
U4-01 [Cumulative OpeTime]
(Ex.) When U4-01 is 12345, 0098 (Hex.) = 1234 and 0099 (Hex.) = 5.
009A -
009B
U4-03 [Fan Oper.Time]
(Ex.) When U4-03 is 12345, 009A (Hex.) = 1234 and 009B (Hex.) = 5.
009C -
00AA
Reserved
Regis
ter No.
(Hex.)
Description
00AB
Drive rated current
Note:
The unit of display is different for different models.
2004 to 2042, 4002 to 4023: 0.01 A
2056 to 2415, 4031 to 4675: 0.1 A
00AC
U1-05
[Motor
Speed]
Units: min
-1
or r/min
Note:
Set Motor Pole Count E2-04, E4-04, E5-04, E9-08.
00AD
Units: 0.01%
00AE,
00AF
Reserved
00B0
Option
codes
connected to
CN5-A
The drive stores option codes in the register.
AI-A3 = 0003 (Hex.)
AO-A3 = 0004 (Hex.)
DI-A3 = 0001 (Hex.)
DO-A3 = 0002 (Hex.)
PG-B3 = 0011 (Hex.)
PG-F3 = 0021 (Hex.)
PG-RT3 = 0023 (Hex.)
PG-X3 = 0012 (Hex.)
SI-C3 = 5343 (Hex.)
SI-EM3 = 1005 (Hex.)
SI-EN3 = 1006 (Hex.)
SI-ET3 = 1004 (Hex.)
SI-N3 = 534E (Hex.)
SI-P3 = 5350 (Hex.)
SI-S3 = 5353 (Hex.)
SI-T3 = 5354 (Hex.)
SI-W3 = 1003 (Hex.)
00B1 Reserved
00B2 Option codes connected to CN5-B
00B3 Option codes connected to CN5-C
00B4 Reserved
00B5
U1-16 [SFS
Output
Frequency]
Units: min
-1
or r/min
Note:
Set Motor Pole Count E2-04, E4-04, E5-04, E9-08.
00B6
Units: 0.01%
00B7
Frequency
reference
monitor
Units: min
-1
or r/min
Note:
Set Motor Pole Count E2-04, E4-04, E5-04, E9-08.
00B8
Units: 0.01%
00B9 -
00BE
Reserved
00BF
Operation error number
xx of oPExx is displayed.
