Q2 Q2A User Manual

Network Communications
6
6.2 Modbus Communications
SIEPYEUOQ2A01G AC Drive Q2A Technical Manual 251
Regis
ter No.
(Hex.)
Description
00D0
CPF Contents 1
bit 0 - 1 Reserved
bit 2 CPF02 [A/D Conversion Error]
bit 3 CPF03 [Control Board Connection Error]
bit 4 - 5 Reserved
bit 6 CPF06 [EEPROM Memory Data Error]
bit 7 CPF07 [Terminal Board Connection Error]
bit 8 CPF08 [Terminal Board Connection Error]
bit 9 Reserved
bit A CPF10 [ASIC Verify Fault]
bit B CPF11 [RAM Fault]
bit C CPF12 [FLASH Memory Fault]
bit D CPF13 [Watchdog Circuit Exception]
bit E CPF14 [Control Circuit Fault]
bit F Reserved
00D1
CPF Contents 2
bit 0 CPF16 [Clock Fault]
bit 1 CPF17 [Timing Fault]
bit 2 CPF18 [Control Circuit Fault]
bit 3 CPF19 [Control Circuit Fault]
bit 4 CPF20 [Control Circuit Error]
bit 5 CPF21 [Control Circuit Error]
bit 6 CPF22 [Hybrid IC Error]
bit 7 CPF23 [Control Board Connection Error]
bit 8 CPF24 [Drive Unit Signal Fault]
bit 9 CPF25 [Terminal Board not Connected]
bit A CPF26 [BB Circuit Error]
bit B CPF27 [PWM Set Reg Error]
bit C CPF28 [PWM Pattern Error]
bit D CPF29 [On-Delay Error]
bit E CPF30 [BB On Error]
bit F CPF31 [ASIC Code Error]
Regis
ter No.
(Hex.)
Description
00D2
CPF Contents 3
bit 0 CPF32 [ASIC Startup Error]
bit 1 CPF33 [Watch-dog Eror]
bit 2 CPF34 [Power/Clock Eror]
bit 3 CPF35 [Ext A/D Conv Error]
bit 4
CPU36 [CPU-ASIC Communication Error]
bit 5
CPU37 [CPU-ASIC Communication Error]
bit 6
CPU38 [EEPROM Data Error]
bit 7
CPU39 [CPU-ASIC Communication Error]
bit 8 CPF40 [Control Circuit Error]
bit 9 CPF41 [EEPROM Memory Data Error]
bit A CPF42 [EEPROM Memory Data Error]
bit B CPF43 [EEPROM Memory Data Error]
bit C CPF44 [EEPROM Memory Data Error]
bit D CPF45 [EEPROM Memory Data Error]
bit E - F Reserved
00D3 -
00D7
Reserved
00D8
oFA0x Description (CN5-A)
bit 0 oFA00 [Option Not Compatible with Port]
bit 1 oFA01 [Option Fault/Connection Error]
bit 2 - 4 Reserved
bit 5 oFA05 [Option A/D Error]
bit 6 oFA06 [Option Communication Error]
bit 7 - F Reserved
00D9
oFA1x Description (CN5-A)
bit 0 oFA10 [Option RAM Error]
bit 1 oFA11 [Option Ope Mode Error]
bit 2 oFA12 [Drive Receive CRC Error]
bit 3 oFA13 [Drive Receive Frame Error]
bit 4 oFA14 [Drive Receive Abort Error]
bit 5 oFA15 [Option Receive CRC Error]
bit 6 oFA16 [Option Receive Frame Error]
bit 7 oFA17 [Option Receive Abort Error]
bit 8 - F Reserved
00DA Reserved
