Q2 Q2A User Manual

Network Communications
6
6.2 Modbus Communications
SIEPYEUOQ2A01G AC Drive Q2A Technical Manual 255
Fault Code
(Hex.)
Name
0098 CPF23 [Control Board Connection Error]
0099 CPF24 [Drive Unit Signal Fault]
009A CPF25 [Terminal Board not Connected]
009B CPF26 [BB Circuit Error]
009C CPF27 [PWM Set Reg Error]
009D CPF28 [PWM Pattern Error]
009E CPF29 [On-Delay Error]
009F CPF30 [BB On Error]
00A0 CPF31 [ASIC Code Error]
00A1 CPF32 [ASIC Startup Error]
00A2 CPF33 [Watch-dog Eror]
00A3 CPF34 [Power/Clock Eror]
00A4 CPF35 [Ext A/D Conv Error]
00A5
CPF36 [ASIC COM Error]
00A6
CPF37 [ASIC COM Error]
00A7
CPF38 [EEPROM Data Error]
00A9 CPF40 [Control Circuit Error]
00AA CPF41 [Control Circuit Error]
00AB CPF42 [Control Circuit Error]
00AC CPF43 [Control Circuit Error]
00AD CPF44 [Control Circuit Error]
00AE CPF45 [Control Circuit Error]
0101 oFA00 [Option Not Compatible with Port]
0102 oFA01 [Option Fault/Connection Error]
0106 oFA05 [Option A/D Error]
0107 oFA06 [Option Communication Error]
0111 oFA10 [Option RAM Error]
0112 oFA11 [Option Ope Mode Error]
0113 oFA12 [Drive Receive CRC Error]
0114 oFA13 [Drive Receive Frame Error]
0115 oFA14 [Drive Receive Abort Error]
0116 oFA15 [Option Receive CRC Error]
0117 oFA16 [Option Receive Frame Error]
0118 oFA17 [Option Receive Abort Error]
0131 oFA30 [COM ID Error]
0132 oFA31 [Type Code Error]
0133 oFA32 [SUM Check Error]
0134 oFA33 [Option Receive Time Over]
0135 oFA34 [Modbus Time Over]
0136 oFA35 [Drive Receive Time Over 1]
0137 oFA36 [CI Check Error]
0138 oFA37 [Drive Receive Time Over 2]
0139 oFA38 [Control Reference Error]
013A oFA39 [Drive Receive Time Over 3]
013B oFA40 [CtrlResSel 1Err]
013C oFA41 [Drive Receive Time Over 4]
Fault Code
(Hex.)
Name
013D oFA42 [CtrlResSel 2Err]
013E oFA43 [Drive Receive Time Over 5]
0201 oFb00 [Option Not Compatible with Port]
0202 oFB01 [Option Fault/Connection Error]
0203 oFb02 [Duplicate Options]
0206 oFb05 [Option A/D Error]
0207 oFb06 [Option Communication Error]
0211 oFb10 [Option RAM Error]
0212 oFb11 [Option Ope Mode Error]
0213 oFb12 [Drive Receive CRC Error]
0214 oFb13 [Drive Receive Frame Error]
0215 oFb14 [Drive Receive Abort Error]
0216 oFb15 [Option Receive CRC Error]
0217 oFb16 [Option Receive Frame Error]
0218 oFb17 [Option Receive Abort Error]
0231 oFb30 [Comm. ID Error]
0232 oFb31 [Model Code Error]
0233 oFb32 [Checksum Error]
0234 oFb33 [Comm. Option Timeout Waiting for Response]
0235 oFb34 [Modbus Ccommunications Timeout]
0236 oFb35 [Drive Timeout Waiting for Response]
0237 oFb36 [CI Check Error]
0238 oFb37 [Drive Timeout Waiting for Response]
0239 oFb38 [Control Command Selection Error]
023A oFb39 [Drive timeout waiting for response]
023B oFb40 [Control Response Selection 1 Error]
023C oFb41 [Drive Timeout Waiting for Response]
023D oFb42 [Control Response Selection 2 Error]
023E oFb43 [Drive Timeout Waiting for Response]
0301 oFC00 [Option Not Compatible with Port]
0302 oFC01 [Option Fault/Connection Error]
0303 oFC02 [Duplicate Options]
0306 oFC05 [Option A/D Error]
0307 oFC06 [Option Communication Error]
0311 oFC10 [Option RAM Error]
0312 oFC11 [Option Ope Mode Error]
0313 oFC12 [Drive Receive CRC Error]
0314 oFC13 [Drive Receive Frame Error]
0315 oFC14 [Drive Receive Abort Error]
0316 oFC15 [Option Receive CRC Error]
0317 oFC16 [Option Receive Frame Error]
0318 oFC17 [Option Receive Abort Error]
0351 oFC50 [Encoder Option A/D Conv Error]
0352 oFC51 [EncOpAnlgCrctErr]
0353 oFC52 [Encoder Option Comm Timeout]
0354 oFC53 [Encoder Option Comm Data Fault]
