Parameter Details
12
12.2 b: APPLICATION
SIEPYEUOQ2A01G AC Drive Q2A Technical Manual 583
■ b9-02 Zero Servo Width for Completion
No.
(Hex.)
Name Description
Default
(Range)
b9-02
(01DB)
Zero Servo Width for
Completion
Sets the range to trigger an output terminal set for “Zero Servo Complete” during Zero Servo
operation. Be sure to set the deviation from the Zero Servo start position.
10
(0 - 16383)
When the position of the motor shaft is in the range of “Zero Servo start position ± b9-02”, the drive will activate a
MFDO set for ZeroServo ok [H2-xx = 8].
