2.9 Installation Methods
62 SIEPYEUOQ2A01G AC Drive Q2A Technical Manual
Figure 2.66 Panel Cut-Out Dimensions
Table 2.5 Panel Cut-Out Dimensions (200 V Class)
Model
Dimensions mm (in.)
W H D1 D2 W1 W2 W3 W4 H1 H2 H3 H4 H5 A B d1
2004
2006
2010
2012
2018
2021
2030
2042
*1
140
(5.51)
294
(11.57)
138
(5.43)
38
(1.50)
102
(4.02)
102
(4.02)
16
(0.63)
3
(0.12)
282
(11.10)
23
(0.91)
6
(0.24)
26
(1.02)
6
(0.24)
134
(5.28)
233
(9.17)
M5
2056
*1
180
(7.09)
329
(12.95)
134
(5.28)
68
(2.68)
140
(5.51)
140
(5.51)
17
(0.67)
3
(0.12)
318
(12.52)
23.5
(0.93)
5
(0.20)
24.5
(0.97)
6
(0.24)
174
(6.85)
270
(10.63)
M5
