12.4 d: REFERENCE
628 SIEPYEUOQ2A01G AC Drive Q2A Technical Manual
■ d7-01 Offset Frq 1
No.
(Hex.)
Name Description
Default
(Range)
d7-01
(02B2)
RUN
Offset Frq 1
Sets the value to add to or subtract from the frequency reference when H1-xx = 0E [H1-xx: MFDI
Function Select = Offset Frq 1] as a percentage of E1-04 [Max Output Frequency].
0.0%
(-100.0 - +100.0%)
■ d7-02 Offset Frq 2
No.
(Hex.)
Name Description
Default
(Range)
d7-02
(02B3)
RUN
Offset Frq 2
Sets the value to add to or subtract from the frequency reference when H1-xx = 0F [H1-xx: MFDI
Function Select = Offset Frq 2] as a percentage of E1-04 [Max Output Frequency].
0.0%
(-100.0 - +100.0%)
■ d7-03 Offset Frq 3
No.
(Hex.)
Name Description
Default
(Range)
d7-03
(02B4)
RUN
Offset Frq 3
Sets the value to add to or subtract from the frequency reference when H1-xx = 10 [H1-xx: MFDI
Function Select = Offset Frq 3] as a percentage of E1-04 [Max Output Frequency].
0.0%
(-100.0 - +100.0%)
